Networking
| Multicast support |
Y |
| Number of VPN connections |
250000 |
| Number of VLANs |
200 |
| Quality of Service (QoS) support |
Y |
| DHCP client |
Y |
| DHCP server |
Y |
| VPN tunnels quantity |
1500 |
| Number of users |
1000 user(s) |
Other features
| Authentication method |
SSO, LDAP |
| Interface |
10/100/1000 LAN |
| Special features |
3G USB Adapter Modem |
| Compliance industry standards |
IEEE 802.11 a/b/g/n |
| Networking features |
Gigabit Ethernet |
Performance
| Heat dissipation |
225 BTU/h |
Data transmission
| VPN throughput |
1024 Mbit/s |
| Firewall throughput |
2816 Mbit/s |
Protocols
| Management protocols |
HTTP, HTTPS, SSH, SNMP v2 |
| Supported network protocols |
TCP/IP, UDP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3 |
| Routing protocols |
OSPF |
Design
| Rack mounting |
Y |
| Form factor |
1U |
NSA 4500 Secure Upgrade Plus 2 Yrs, 1U, 2816 Mbit/s, 200 VLANs, Gigabit Ethernet, 802.11 a/b/g/n, 2x USB 2.0, 512MB RAM, SonicOS Enhanced
The SonicWALL® NSA 4500 is a next generation Unified Threat Management firewall, utilizing a breakthrough multi-core hardware design with 8 cores and 6 Gigabit Ethernet interfaces to deliver real-time internal and external network protection without compromising network performance for corporate networks and distributed environments. The NSA 4500 combines high-speed intrusion prevention, file & content inspection and powerful application firewall capabilities with an extensive array of advanced networking, high availability and configuration flexibility.
