Ports & interfaces
Combo headphone/mic port |
Y |
USB 3.0 (3.1 Gen 1) Type-A ports quantity |
3 |
Host interface |
USB 3.0 (3.1 Gen 1) Type-C |
Microphone in |
N |
DC-in jack |
Y |
HDMI ports quantity |
1 |
VGA (D-Sub) ports quantity |
1 |
USB connector type |
USB Type-A |
Networking
Ethernet LAN data rates |
10, 100, 1000 Mbit/s |
Additionally
Mini DisplayPort quantity |
1 |
Ethernet LAN connection |
Y |
AC adapter bundled |
Y |
Ethernet LAN (RJ-45) ports quantity |
1 |
2 x USB 2.0, 3 x USB 3.0, 1 x HDMI, 1 x mini DisplayPort, 1 x VGA, 1 x LAN, 130W, 422 g
<b>Single Cable Connectivity</b>
Featuring a powerful DisplayPort over USB Type-CTM cable, with the Dell Dock you can quickly connect your laptop or tablet to a single data and power source up to 130W for Dell devices and 60W for non-Dell devices. You’ll also enjoy an easy, reliable connection from your laptop or tablet to dual FHD displays or a single 4k display @ 30Hz, and all your essential peripherals.
<b>Small Footprint and Big Flexibility</b>
The Dell Dock is small in size-just 6.1 x 4.3 x .83 inches (15.49 x 10.92 x 2.11 cm)-and has one single cable. Place it anywhere you want to work-in your traditional office workspace, a hot desk or a conference room-even if space is limited.
<b>One dock for all</b>
The Dell Dock is compatible with select Dell laptops, workstations, tablets and many compatible non-Dell devices with USB-Type CTM port(s) having data, video, and power capabilities. Easily connect to displays, a mouse, keyboard and audio devices through the Dell Dock from your compatible system of choice.
<b>Connect for collaboration</b>
Grab your laptop and head to the next meeting where you, and your co-workers, will be able to quickly connect to the Dell Dock and share your latest PowerPoint presentation through a connected display screen or projector.
<b>Enhanced video performance</b>
USB Type-CTM connectivity is the latest and extremely reliable technology for video performance. Your display will be crisp and clear.
<b>Connections and Features:</b>
- Supports 2 FHD displays
- Two USB 2.0 ports
- Three USB 3.0 ports
- Speaker output (rear)
- Combo audio (front)
- Gigabit Ethernet
- Kensington Lock Slot
- 130W AC adapter with 7.4mm barrel
<b>What’s in the box</b>
- Dell Dock
- DisplayPort over USB Type-CTM Cable
- 130W AC Adapter with 7.4 mm barrel
- Quick Setup Guide
<b>Compatibility</b>
This product is compatible with the following systems:
A system requiring more than 130 Watts must have its own power adapter attached
- Inspiron 13 5000 Series (5368)
- Inspiron 13 7000 Series (7368)
- Inspiron 15 5000 Series (5568)
- Inspiron 15 7000 Series (7569)
- Inspiron 17 7000 Series (7778)
- Latitude 11 (5175)
- Latitude 11 (5179)
- Latitude 7275
- Latitude 7370
- Venue 10 Pro (5056)
- Venue 8 Pro (5855)
- XPS 12 (9250)
- XPS 13 (9350)
