Performance
| Processor frequency |
100 MHz |
| Internal memory |
16 MB |
Other features
| Other network protocols supported |
V.21, V.22, V.22bis, Bell 103, Bell 212A, V.32, V.32bis, V.34, V.42, V.42bis, V.90, MNP4, MNP5 |
| Ports quantity |
4 |
| Form factor |
Full-size PCI |
Ports & interfaces
| Host interface |
PCI |
| Internal |
Y |
Protocols
| Management protocols |
SNMP |
Certificates
| Safety |
UL 60950, CSA 60950, EN 60950 |
| Electromagnetic compatibility |
FCC part 15, ICES-003, EN55022, EN55024 |
Additionally
| Ethernet LAN connection |
Y |
| Wireless technologies |
Wired |
Diva Server V-Analog-8P
are available in 2-port, 4-port, and 8-port variants, offering standard RJ-11 interfaces to connect to public and private switching systems via analog trunk interfaces. Diva Analog boards provide powerful onboard CPU and Digital Signaling Processor (DSP) resources - one dedicated to each communication channel. Thanks to providing high-performance media processing functions such as V.90 data modem, V.34 fax receiver and transmitter, Voice over IP (VoIP) streaming, voice compression, and echo cancellation onboard, the Diva Analog boards enhance overall system performance and lower implementation costs. Based on the latest industry standards, the Diva Analog boards work in any PCI and PCI-X based server platform and demonstrate best-in-class system design, resulting in minimum power consumption and maximum heat dissipation.
The Diva Analog boards also support a common and consistent set of programming interfaces. This allows application developers and system integrators to minimize porting effort and reduce time to market. Whether using industry standard CAPI and TAPI, or the Dialogic® Diva® API via the Dialogic® Diva® Software Development Kit (SDK), an application once designed to work with any Dialogic® Diva® board can also be used seamlessly with the Diva Analog boards.
