Antenna
| Antenna connector type |
RP-SMA |
GSM 850/900/1800/1900 MHz, RS232, SMA connector
Pocket AL I/O QB is a monitoring and remote control system of sensors that uses the SMS service via GSM.
Pocket AL I/O QB is the solution for the remote management of digital and analog detectors in industrial and residential environment.
It is able to control up to 6 digital inputs, 6 outputs and 2 analog inputs to connect the various models of sensors for the detection of doors opening, gas escapes, fumes alarm, level sensors, etc. and to send an SMS message at any change detected on each single sensor.
You will receive the information via SMS on your mobile phone, for example if a change occurs on the gas or temperature sensor at your home.
You can also remote interact by sending appropriate SMS that will pilot the opening/closing of the 6 outputs.
The device installation is fast and simple. The configuration can be performed through a common GSM phone sending SMS messages or via serial port with the Windows utility.
Pocket AL I/O QB watches over your house or your industrial installation even if a power blackout occurs thanks to the built-in rechargeable backup battery. You will be informed of the power off and restore, so no more surprise when you come back from holidays.
When using the device in M2M environment (Machine To Machine), a particular firmware management has been provided in order to automate your application and to independently use a couple of Pocket AL I/O QB with no need of specialized personnel on site (1).
In the GATE application instead, through a simple phone ring with no answer, you will be able to remote control your Pocket AL I/O QB using the mobile phone to open the home gate, the parking bar for a limited time, the access to restricted areas as wharf, camping or private clubs.
The design is compact and the case is made of aluminium with two wings for the wall mount; it’s the ideal products even in the most extreme solutions of industrial environments.
The power range is wider, from 5 to 32Vdc with a considerable low consumption so that Pocket AL I/O QB can be used in various applications. Also a power supply through solar panel can be taken into considerations.
