Performance
| Motherboard form factor |
Micro ATX |
| Motherboard chipset family |
Intel |
| Audio system |
HD Audio |
| Component for |
PC |
| Energy Star certified |
N |
Memory
| Supported memory clock speeds |
1600 MHz |
| Non-ECC |
Y |
| Unbuffered memory |
Y |
| Supported memory types |
DDR3-SDRAM |
| Memory channels |
Dual |
| Memory slots type |
DIMM |
| Number of memory slots |
4 |
| Maximum internal memory |
32 GB |
Processor
| Maximum number of SMP processors |
1 |
BIOS
| BIOS type |
AMI |
| Clear CMOS jumper |
Y |
Internal I/O
| USB 2.0 connectors |
3 |
| ATX Power connector (24-pin) |
Y |
| TPM connector |
Y |
| USB 3.0 (3.1 Gen 1) connectors |
1 |
| Number of SATA III connectors |
6 |
| Peripheral (Molex) power connectors (4-pin) |
1 |
| CPU fan connector |
Y |
| Chassis intrusion connector |
Y |
| Front panel audio connector |
Y |
| Serial port headers |
1 |
Processor special features
| Intel® Small Business Advantage (Intel® SBA) |
Y |
| Intel® Smart Response Technology |
Y |
| Intel® Identity Protection Technology (Intel® IPT) |
Y |
| Intel Hyper-Threading Technology |
Y |
| Intel® Turbo Boost Technology |
2.0 |
Expansion slots
| PCI slots |
1 |
| PCI Express x1 (Gen 2.x) slots |
1 |
| PCI Express x16 (Gen 2.x) slots |
1 |
| PCI Express x16 (Gen 3.x) slots |
1 |
Back panel I/O ports
| PS/2 ports quantity |
1 |
| Headphone outputs |
1 |
| Microphone in |
Y |
| DVI-I ports quantity |
1 |
| USB 3.0 (3.1 Gen 1) Type-A ports quantity |
4 |
| HDMI ports quantity |
1 |
| VGA (D-Sub) ports quantity |
1 |
Additionally
| Chipset |
Intel H87 |
| System bus data transfer rate |
5 GT/s |
| Ethernet LAN connection |
Y |
| Ethernet LAN (RJ-45) ports quantity |
1 |
Intel H87 Express, LGA1150, 4x DDR3 DIMM, 6x SATA3, AMD CrossFire, Gigabit Ethernet, USB3.0/2.0, HDMI, DVI-I, VGA, AMI BIOS, mATX
Durathon Technology - Motherboard quality you can trust.
When it comes to the quality and durability of your motherboard, ECS goes above and beyond industry standards to ensure that you have a motherboard that will last long and always continue to out perform the competition. Trust only motherboards built with Durathon Technology. Click " Durathon microsite" for more details.
ATI CrossFireX™ Technology Ready
Combining multi-GPU to deliver users a highest image quality and screen resolutions.
ECS EZ BIOS
ECS EZ BIOS is an exclusive design and the most convenient tool to adjust BIOS in graphical interface. Designed with stunning user-friendly interface and easy-to-use function including Auto OC, boost priority, and security function, EZ BIOS can radically take full advantage of the performance, high-end gaming, multi-tasking and energy efficiency. The latest ECS EZ BIOS allow users to fully satisfy their growing demand with the unique operating designed.
Support HD Video Playback
Smoothly playback all H.264, VC-1, and MPEG-2 video with minimal CPU usage through integrated Graphics in chipset or CPU.
DirectX® 11 Support
DirectX 11 features the latest technologies of Compute Shaders, Direct 2D, Multithreaded Rendering and Tessellation for create rich worlds, realistic characters and more fluid gameplay.
Anti-Static Design - ESD Protection
ESD protection design helps to avoid suffering permanent damage when subjected to momentary high voltages to increase the lifespan of motherboard. All ECS motherboards pass ESD International standard EC/EN 61000-4-2 Test and bring you stability and durability quality.
Speedy Storage Interface - SATA 6G
Double the transfer speed of SATA 3.0 Gb/s, running at speed up to amazing 6.0Gb/s.
4K Video Output
Intel Core HD Graphics with 4k display for premium gaming experience with 2.6x graphics improvements.
Full Duplex Operation Support - USB 3.0
Ten times the transfer speed of USB2.0, running at speed up to amazing 4.9Gb/s.
PCI Express Gen3 Ready - Double PCIe 2.0 Bandwidth
PCIe 3.0, the next generation of 32GB/s transmission speed, doubles the bandwidth of previous generation interconnect. PCIe 3.0 strongly builds up a better gaming platform ready for ultra graphics performance.
3X Current Supply for ECS EZ Charger
EZ Charger technology provides 3 times current than general USB port for USB devices. It’s useful and excellent, especially for the iPhone, iPAD and iPod touch devices that need a large amount of current for faster recharging within less time.
Motherboard Intelligent BIOS III (M.I.B III)
Providing the most intelligent and convenient way to adjust the clock/ voltage settings of CPU and memory and get the extra performance in advanced.(Certain models could only adjust GPU setting according to chipset limitation.)
M.I.B. III brings the same convenience interface of overclocking as M.I.B. II, it also comes with advance range of frequency tuning for system performance and superior gaming capability.
CyberLinkMedia Suite Bundled
Bundled the Ultimate HD & Blu-ray Player ,Best Video Editing and Backup/Burn Softwares. (30 Days Trial Version)
Intel® Small Business Advantage
Intel® SBA delivers the enhanced security & productivity for PCs that small businesses demand
- Unique combination of hardware & software
- Delivers compelling “out-of-the-box” capabilities
- Development platform for future innovation
