Performance
| Surge protection |
Y |
| Number of phases |
1 |
| Audible alarm(s) |
Y |
| EMI/RFI noise filtering |
Y |
| Cooling type |
Passive |
| Power protection features |
Over voltage, Overload, Short circuit |
| Surge protection features |
Fax, Modem, Telephone |
Power
| Input operation voltage (max) |
264 V |
| Input operation voltage (min) |
160 V |
| Output power capacity |
1200 VA |
| Output operation voltage (min) |
230 V |
| Output operation voltage (max) |
230 V |
| Output power |
780 W |
Ports & interfaces
| Modem (RJ-11) ports |
2 |
| Power plug |
C14 coupler |
| AC outlets quantity |
4 AC outlet(s) |
Battery
| Number of battery cells |
2 |
| Hot-swap battery |
N |
| Battery recharge time |
7 h |
| Typical backup time at half load |
10 min |
| Typical backup time at full load |
4.5 min |
| Replacement battery cartridge |
2 x 12V 7Ah |
| Automatic battery test |
Y |
| Battery replacement alarms |
Audible, LED |
| Battery type |
VRLA |
Other features
| Networking features |
N |
| Nominal output voltage |
230 V |
Operational conditions
| Operating altitude |
0 - 1000 m |
Additionally
| RS-232 port |
1 |
| Filtering |
LC |
Sinline 1200VA/780W
SINLINE series provides for the professional protection of small computer networks: servers and workstations, including DTP workstations.
SINLINE series UPS are fitted with unique systems, which were developed by EVER’s engineers: "Clear Digital Sinus (CDS)" - digital hardware system that enables, both for grid supply and battery mode, voltage generation the UPS output with a clear, sinusoidal waveform, as well as "Cool Battery Charging" (CBC), which significantly prolongs battery life.
This series is also equipped with an RS 232 interface and the automatic voltage regulation system (AVR).
Application: servers, PC computers, computer terminals, devices sensitive to power outages, and telecommunication devices. Sinline series provides intelligent and safe power supply to computer hardware with a guaranteed "clear sinusoidal waveform" at the output in battery mode.
This series comprises the following models:
Sinline 800, Sinline 1200, Sinline 1600, Sinline 2000, Sinline 3000.
The user can use extended switching thresholds with the following parameters:
- grid - ups: ~145V - ~280V +/- 2%
- ups - grid: ~150V - ~275V +/- 2%
