Storage
| Hard drive size |
3.5 " |
| Number of hard drives supported |
3 |
| RAID support |
Y |
| Total installed storage capacity |
12000 GB |
| Hard drive interface |
Serial ATA |
Performance
| Video loss detection |
Y |
| Networking standards |
IEEE 802.3 |
| E-map function |
Y |
| Maximum resolution |
1280 x 1024 pixels |
| Video formats supported |
H.264, MPEG4 |
| Video motion detection |
Y |
| PTZ control (Pan/Tilt/Zoom) |
Y |
| Maximum frame rate |
30 fps |
| Image formats supported |
MJPEG |
| Backup function |
Y |
| Video input channels |
8 channels |
Power
| Power consumption (typical) |
300 W |
| Output voltage |
24 V |
Weight & dimensions
| Depth |
312.4 mm |
| Weight |
6804 g |
| Width |
414 mm |
| Height |
86.36 mm |
Ports & interfaces
| RAID levels |
5 |
| DVI-I ports quantity |
1 |
| HDMI ports quantity |
1 |
| VGA (D-Sub) output ports |
1 |
Additionally
| Colour of product |
Black, Silver |
| Выход HDMI |
Y |
| Ethernet LAN (RJ-45) ports quantity |
1 |
| Operating temperature range (T-T) |
0 - 40 °C |
MPEG4, MJPEG, H.264, 8CH, 1280 x 1024, RJ45, 1 x VGA, 1 x DVI, 1 x HDMI, PTZ, 300 W, 6.8 kg, RAID5, 12 TB
- Accepts MPEG4/MJPEG/H.264 video format
- Up to 32 channel or more video management from megapixel cameras, IP cameras and video servers
- Back-up video images to USB drives, CD/DVD or HDD
- Smart detection on many types of camera, input, POS and system events, with 10 potential instant alarm repsonses (e.g. email alert & E-map pop-up)
- Export to AVI or ASF file format
- User friendly GUI with camera ‘drag and drop’ for setup and recording, familiar to all users with basic PC knowledge
- Watermark capability
- DDNS functionality
- 3GPP/PDA/Mobile Handy Viewer support
- Intelligent playback system with 5 video analytic searches
- Remote client viewer, playback, backup, I/O control and remote desktop operation
- Audio and Video Synchronization
- Joystick support on PTZ cameras (with optional EKB200) and software enabled digital PTZ function are both available. Preset points and patrol functions are also available on many camera models
- Unusual events are recorded to the system log, and counting application result can be exported to an Excel or text file for analysis
- Multiple monitor display with 36 cameras in Live View and 36 cameras in Playback View
- Remote PTZ operation supports PTZ reaction presets
- Video Enhancement tools to fine tune the image’s visibility, sharpness, brightness, contrast or even grayscale
- Resource Management tool can monitor system resources and trigger instant alarm notifications
- Intelligent Search (general motion, missing object, foreign object, camera occlusion and signal lost)
- Counting application with direction for certain objects or areas
- Take snapshots from recording in BMP or JPEG format to print or save file
- Local view with 1 or (optional) 2 monitors for Live View plus (optional) 1 monitor dedicated for simultaneous Playback
