Ports & interfaces
| DVI port |
Y |
| Line-out |
Y |
| Line-in |
Y |
| PS/2 ports quantity |
2 |
| Microphone in |
Y |
| DisplayPorts quantity |
1 |
| USB 3.0 (3.1 Gen 1) Type-A ports quantity |
4 |
| VGA (D-Sub) ports quantity |
1 |
Processor
| Processor cache |
2 MB |
| Processor cores |
2 |
| Processor frequency |
2.2 GHz |
Graphics
| Graphics adapter manufacturer |
Intel |
Expansion slots
| PCI Express x1 slots |
1 |
| PCI Express x16 slots |
1 |
Multimedia
| Audio system |
Realtek ALC671 |
Memory
| Internal memory type |
DDR3-SDRAM |
| Number of memory slots |
1 |
| Memory slots type |
DIMM |
| Memory clock speed |
1600 MHz |
| Maximum internal memory |
8 GB |
| Internal memory |
4 GB |
Storage
| Total storage capacity |
500 GB |
| Storage media type |
HDD |
| Hard drive interface |
Serial ATA III |
| Hard drive capacity |
500 GB |
Networking
| Ethernet LAN data rates |
1000, 100, 10 Mbit/s |
Additionally
| Chipset |
Intel Q87 |
| Ethernet LAN connection |
Y |
| RS-232 port |
2 |
| Graphics |
HD Graphics |
| Ethernet LAN (RJ-45) ports quantity |
1 |
Intel Celeron G1820TE (2M Cache, 2.20 GHz), 4GB RAM, 500GB HDD, Gigabit Ethernet, Windows 10 Pro
The Fujitsu TeamPoS 7000 S-Series modular controller incorporates Intel 4th generation Core technology to support the most demanding retail applications. With a volume of just 7 litres (1.85 gallons), it can be simply deployed in the most challenging environments. Enhanced
connectivity, with powered USB and Serial ports, enables a full complement of retail peripherals to be connected and powered directly from the unit, removing the need for external power bricks and simplifying deployment and improving reliability. With its 90%+ efficient power supply, energy costs and heat output are minimized to deliver a low TCO and lengthen service life.
<b>Compact design with horizontal or vertical deployment</b>
- Simple installation in the most constrained of environments. Can replace existing equipment
without furniture changes. Provides maximum space at counter for other equipment, or display material
<b>Intel 4th Generation Core technology from Celeron® to i5 vPro</b>
Future proof processing power that scales across the organization. Latest AMT remote
management technology reduces cost of ownership and helps increase availability
<b>Great connectivity with full complement of retail ports and integrated dual storage drives</b>
Enhanced retail connectivity removes need for external power bricks and enables operation from single power outlet. This reduces installation costs, lowers energy consumption and improves reliability. Dual SSD / HDD storage drives with RAID delivers high levels of data protection
<b>90% efficiency integrated power supply</b>
Reduces energy costs and carbon footprint. Lower heat output reduces store cooling costs and improves reliability. Patented power management controls processing power during peak
peripheral demand to ensure reliable operation
<b>Made in Germany in state of the art automated factory</b>
Quality manufacturing and engineering processes, with selected long-life components, ensures trouble-free 24x7 operation in retail environment
