Processor special features
| Intel Rapid Storage Technology |
N |
| Graphics & IMC lithography |
22 nm |
| Intel Fast Memory Access |
Y |
| Intel Flex Memory Access |
Y |
| Execute Disable Bit |
Y |
| Idle States |
Y |
| Thermal Monitoring Technologies |
Y |
| Intel Trusted Execution Technology |
N |
| Intel® Small Business Advantage (Intel® SBA) |
N |
| Intel Virtualization Technology (VT-x) |
Y |
| Processor package size |
31 mm |
| Processor ARK ID |
65707 |
| Processor code |
SR0N8 |
| Intel® Quick Sync Video Technology |
Y |
| Intel® Insider™ |
Y |
| Intel 64 |
Y |
| Intel Clear Video Technology |
N |
| Intel Dual Display Capable Technology |
Y |
| CPU configuration (max) |
1 |
| Embedded options available |
N |
| Intel Virtualization Technology for Directed I/O (VT-d) |
Y |
| Intel® Smart Cache |
Y |
| Intel® Anti-Theft Technology (Intel® AT) |
Y |
| Intel® Identity Protection Technology (Intel® IPT) |
Y |
| Intel Hyper-Threading Technology |
Y |
| Intel® Turbo Boost Technology |
2.0 |
| Intel Enhanced Halt State |
Y |
| Intel® Secure Key |
Y |
| Intel Clear Video Technology for MID |
N |
| Intel vPro Technology |
N |
| Intel VT-x with Extended Page Tables (EPT) |
Y |
| Intel FDI Technology |
Y |
| Enhanced Intel SpeedStep Technology |
Y |
| Intel Identity Protection Technology version |
1.00 |
| Intel Secure Key Technology version |
1.00 |
| Intel Demand Based Switching |
N |
| Intel® Wireless Display (Intel® WiDi) |
Y |
| Intel® Clear Video HD Technology (Intel® CVT HD) |
Y |
| Supported instruction sets |
AVX |
| Intel® My WiFi Technology (Intel® MWT) |
Y |
Graphics
| On-board graphics adapter |
Y |
| On-board graphics adapter ID |
0x166 |
| On-board graphics adapter family |
Intel HD Graphics |
| Discrete graphics adapter model |
NVIDIA GeForce GT 640 |
| On-board graphics adapter base frequency |
350 MHz |
| On-board graphics adapter dynamic frequency (max) |
1050 MHz |
| Number of displays supported (on-board graphics) |
3 |
Processor
| Processor cache |
3 MB |
| Processor lithography |
22 nm |
| Thermal Design Power (TDP) |
17 W |
| Maximum number of PCI Express lanes |
1 |
| Processor codename |
Ivy Bridge |
| Memory clock speeds supported by processor |
1333, 1600 MHz |
| Memory channels supported by processor |
Dual |
| Conflict Free processor |
Y |
| PCI Express configurations |
1x16, 2x8, 1x8+2x4 |
| Memory bandwidth supported by processor (max) |
25.6 GB/s |
| Processor cache type |
Smart Cache |
| Integrated 4G WiMAX |
Y |
| Tjunction |
105 °C |
| FSB Parity |
N |
| CPU multiplier (bus/core ratio) |
17 |
| Processor operating modes |
64-bit |
| Processor socket |
BGA 1023 |
| Processor frequency |
1.7 GHz |
| Maximum internal memory supported by processor |
32 GB |
| ECC supported by processor |
N |
| Memory types supported by processor |
DDR3-SDRAM, DDR3L-SDRAM |
| Bus type |
DMI |
| PCI Express slots version |
2.0 |
| Number of processors installed |
1 |
| Processor boost frequency |
2.6 GHz |
| Stepping |
L1 |
| Processor cores |
2 |
Storage
| Solid-state drive capacity |
32 GB |
| Number of SSDs installed |
1 |
| Hard drive capacity |
500 GB |
| Hard drive speed |
5400 RPM |
| Compatible memory cards |
Memory Stick (MS), MMC, MS PRO, SD |
| Hard drive interface |
Serial ATA |
| Number of hard drives installed |
1 |
| Hard drive size |
2.5 " |
| Total storage capacity |
532 GB |
| Card reader integrated |
Y |
Ports & interfaces
| Thunderbolt ports quantity |
1 |
| Line-out |
Y |
| USB 3.0 (3.1 Gen 1) Type-A ports quantity |
3 |
| HDMI ports quantity |
1 |
| DC-in jack |
Y |
| Serial ports quantity |
3 |
| S/PDIF out port |
Y |
| Microphone in |
Y |
| eSATA ports quantity |
1 |
Other features
| Floppy drive installed |
N |
| HDMI |
Y |
Networking
| Ethernet LAN data rates |
10, 100, 1000 Mbit/s |
| Wi-Fi |
Y |
| Bluetooth |
Y |
| Cabling technology |
10/100/1000Base-T(X) |
Performance
| Audio output channels |
7.1 channels |
Optical drive
| Optical drive type |
Blu-Ray DVD Combo |
Memory
| Maximum internal memory |
8 GB |
| Internal memory |
4 GB |
| Internal memory type |
DDR3-SDRAM |
Additionally
| InTru™ 3D Technology |
Y |
| Chipset |
Intel HM77 Express |
| Ethernet LAN connection |
Y |
| System bus data transfer rate |
5 GT/s |
| Intel AES New Instructions |
Y |
| Ethernet LAN (RJ-45) ports quantity |
1 |
Intel Core i5-3317U (3M Cache, up to 2.60 GHz), 4GB DDR3, 500GB HDD + 32GB SSD, HM77 Express, nVidia GT640, Blu-ray DVD, Gigabit Ethernet, 802.11b/g/n, Bluetooth, HDMI, Audio, S/PDIF
The Giada D2305-i5 is the ultimate home theater PC.
Featuring 3rd generation Intel® Core™ i5 processor, Full HD, 7.1 channel, 500GB HDD, Bluetooth® audio, and a Blu-ray Disc™ drive option.Stream videos effortlessly onto your big screen with this stylish device.
- Built to perform– Intel 3rd Generation Core i5 processor – ideal for playing HD movies and even 3D gaming
- 1080p Full HD Graphics with HDMI port
- 7.1 channel surround sound audio (via HDMI)
- 4GB of high performance DDR3 RAM (expandable to 8GB), 1GB VRAM
- 32GB SSD + 500GB 2.5” hard drive
- DVD-ROM drive (optional Blu-ray Disc drive)
- Built-in 802.11n wireless networking, Gigabit LAN port too!
- Bluetooth Audio
- USB3.0 & 2.0 ports for maximum connectivity
- 4-in-1 Card Reader (SD / MMC / MS / MS PRO)
- Low 90 Watt power consumption
- Quiet operation
- Windows® 8 Pro (Optional)
