Performance
| Motherboard form factor |
Micro ATX |
| Motherboard chipset family |
Intel |
| PC health monitoring |
CPU, FAN, Temperature, Voltage |
| Audio system |
Realtek ALC892 |
| Component for |
PC |
| Cooling type |
Passive |
Memory
| Supported memory clock speeds |
2133 MHz |
| Non-ECC |
Y |
| Unbuffered memory |
Y |
| Supported memory types |
DDR4-SDRAM |
| Memory channels |
Dual |
| Memory slots type |
DIMM |
| Number of memory slots |
4 |
| Maximum internal memory |
64 GB |
BIOS
| BIOS memory size |
16 MB |
| BIOS type |
UEFI AMI |
| Clear CMOS jumper |
Y |
| ACPI version |
5.0 |
Processor
| Maximum number of SMP processors |
1 |
| Intel Core i3/i5/i7 series |
i3-6xxx, i5-6xxx, i7-6xxx |
Internal I/O
| USB 2.0 connectors |
2 |
| S/PDIF out connector |
Y |
| ATX Power connector (24-pin) |
Y |
| TPM connector |
Y |
| USB 3.0 (3.1 Gen 1) connectors |
2 |
| Number of SATA III connectors |
6 |
| EPS power connector (8-pin) |
Y |
| Parallel connector |
Y |
| CPU fan connector |
Y |
| Number of chassis fan connectors |
3 |
| Front panel audio connector |
Y |
| Serial port headers |
1 |
| Thunderbolt headers |
1 |
| Number of SATA Express ports |
2 |
Graphics
| Maximum graphics adapter memory |
512 MB |
| Discrete graphics support |
Y |
Back panel I/O ports
| DVI-D ports quantity |
1 |
| PS/2 ports quantity |
1 |
| Headphone outputs |
1 |
| Microphone in |
Y |
| USB 3.0 (3.1 Gen 1) Type-A ports quantity |
4 |
| HDMI ports quantity |
1 |
| VGA (D-Sub) ports quantity |
1 |
Expansion slots
| PCI slots |
2 |
| PCI Express x16 (Gen 3.x) slots |
2 |
Additionally
| Chipset |
Intel H170 |
| Ethernet LAN connection |
Y |
| Ethernet LAN (RJ-45) ports quantity |
1 |
GA-H170M-D3H, LGA 1151, Intel H170, 4 x DDR4 2133MHz, Intel HD Graphics, 2 x PCI Express x16 (2-Way AMD CrossFire), 6 x SATA 6.0Gb/s, GbE LAN, AMI UEFI DualBIOS, Micro ATX
- Supports 6th Generation Intel® Core™ Processor.
- Dual Channel DDR4, 4 DIMMs.
- 2-Way Graphics with Premium PCIe Lane.
- PCIe Gen3 x4 M.2 Connector with up to 32Gb/s Data Transfer (PCIe NVMe & SATA SSD support).
- 2 SATA Express Connectors for up to 16Gb/s Data Transfer.
- 8-channel HD Audio with High Quality Audio Capacitors.
- Audio Noise Guard with LED Trace Path Lighting.
- Intel® GbE LAN with cFosSpeed Internet Accelerator Software.
- APP Center Including EasyTune™ and Cloud Station™ Utilities.
- GIGABYTE UEFI DualBIOS™ Technology.
- Support Intel® Small Business Advantage.
