MAC address table | 4000 entries |
---|---|
Supported data transfer rates | Full Duplex - 2000Mbps (for 1000BaseT), 200Mbps (for 100BaseTX), 20Mbps (for 10BaseT) |
Maximum data transfer rate | 1 Gbit/s |
Installed ports | 8 x 10/100/1000Mbps RJ-45 ports |
---|
Basic switching RJ-45 Ethernet ports quantity | 8 |
---|
Packet buffer memory | 0.125 MB |
---|
Full duplex | Y |
---|
Features
- Eight 1000BASE-T Gigabit Ethernet ports
- Supports Auto-Negotiation for 10/100/1000Mbps and duplex mode
- Supports Auto-MDIX for each port
- Supports Full/Half duplex transfer mode for 10 and 100Mbps
- Supports full duplex transfer mode for 1000Mbps
- Full wire-speed reception and transmission
- Store-and-forward switching method
- Supports 4K of absolute MAC addresses
- Features 128K Bytes of RAM for data buffering
- Set of front-panel diagnostic LEDs
- IEEE 802.3x flow control for full-duplex
- Back pressure flow control for half-duplex
