Maximum paper trays | 1 |
---|---|
Standard media sizes | A1, A1+, A2, A3, A4, B2, B3, B4, envelopes |
Maximum length of sheet media | 1625 mm |
Custom media sizes | Tray 1: 76 x 142 to 457 x 610 mm; manual sheet feed: 110 x 205 to 625 x 1625 mm; rear path: 110 x 205 to 625 x 1625 mm; roll feed: up to 609 mm |
Roll bottom margin | 5 mm |
Roll left margin | 5 mm |
Roll right margin | 5 mm |
Roll external diameter | 100 mm |
Roll top margin | 5 mm |
Print margin cut-sheet | 5 x 12 x 5 x 5 mm |
Print margin roll | 5 mm |
Media sizes supported (imperial) | Letter, legal, tabloid, C, D, D+, envelopes |
Media thickness (by paper path) | Tray 1: up to 8 mil; envelopes: up to 15 mil; front path: up to 8 mil; rear path: up to 15 mil |
Maximum media width | 625 mm through front manual feed path |
Media handling | Input tray, manual single-sheet feed, rear path (minimum A2, maximum A1 oversize), roll feed through rear path |
Margins, leading/trailing edges | Roll: top and bottom: 5 mm; Sheet: top: 5 mm, bottom: 12 |
Media types supported | Paper (plain, inkjet, coated, heavyweight, semi-gloss, glossy, proofing, photo, brochure/flyer, natural tracing), translucent bond, A4 transparencies |
Duplex print options | None (not supported) |
Lateral margins | Roll: left and right: 5 mm; Sheet: left and right: 5 mm |
Media weights by paper path | Tray 1: 65 to 150 g/m2; manual single-sheet feed: 65 to 150 g/m2; rear path: up to 300 g/m2 |
Standard input trays | 1 |
Recommended media weight | Tray 1: 65 to 150; manual single-sheet feed: 65 to 210; rear path: up to 300; roll feed: 65 to 150 g/m² |
Paper handling | Sheetfed (automatic input tray for 150 sheets up to A2+, front manual single-sheet feed, rear manual path for thick media), optional roll-feed with automatic cutter |
Paper handling optional/input | Optional automatic roll feed, spindle |
Paper handling standard/input | 100-sheet A2-size input tray, manual single-sheet feed, single-sheet rear path for thick media, optional automatic roll feed |
Recommended media weight (imperial) | 17 to 56 lb |
Non-printable area roll media (imperial) | 0.2 x 0.2 x 0.2 x 0.2 in |
Downloadable software | None |
---|
Maximum print length (imperial) | 64 in |
---|---|
ISO B-series sizes (B0...B9) | B2 |
Media sizes standard (imperial rolls) | 3 to 24.6-in wide sheets |
Maximum roll length | 45.7 m |
Maximum printable area (imperial) | 12.6 x 18.3 " |
Maximum media length (imperial) | 63.98 " |
Maximum media width (imperial) | 24.6 " |
Photo paper | Y |
---|---|
Glossy paper | Y |
Coated paper | Y |
Proofing paper | Y |
Acoustic power emissions (standby) | 5.4 B(A) B |
---|---|
Acoustic power emissions | 6.2 B(A) (active, printing), 5.4 B(A) (standby) |
Acoustic pressure emissions (standby) | 37 dB(A) |
Drive device, buffer size | 32 MB |
---|---|
Internal memory | 64 MB |
Processor frequency | 16 MHz |
Maximum output capacity | 50 sheets |
---|---|
Standard output capacity | 50 sheets |
Minimum line width | 0.04 mm |
---|---|
Ink drop | 4 pl (cyan, magenta, yellow), 18 pl (black) |
Printing colours | Cyan |
Printer management | HP Designjet System Maintenance |
Print quality (black, normal quality) | 600 DPI |
Print quality (black, best quality) | 1200 x 600 DPI |
Maximum duty cycle | 7000 pages per month |
Print quality (black, draft quality) | 600 DPI |
Browser supported | Microsoft Internet Explorer 5.5 and above, Netscape 6.1 and above |
---|---|
Mac compatibility | Y |
Minimum system requirements for Macintosh | iMac G3, G4, G5 dual processor; iBook; PowerBook; eMac |
Compatible ink types, supplies | Black: HP pigment ink; cyan, magenta, yellow: HP dye-based ink |
---|---|
Line width minimum | 0.001 in |
Line accuracy | +/- 0.2 % |
JetDirect Compatible Products | Y |
Non-printable area (imperial cut-sheet) | 0.2 x 0.47 x 0.2 x 0.2 in |
Driver updates | Latest driver upgrade information available on http:// |
Control panel | 2 LEDs for status: Power, Attention; 3 keys: Power, Cancel, OK; display area containing information icons |
Print time (color image ISO N5, draft quality, D coated paper) | Up to 1.5 min/page min/page |
---|---|
Print time (colour image ISO N5, normal quality, D coated paper) | Up to 5 min/page min/page |
Print time (color image ISO N5, best quality, B coated paper) | Up to 5 min/page min/page |
Print time colour line drawing (best, D) | Up to 4 min/page |
Print time colour line drawing (draft, A1) | Up to 1.5 min/page |
Print time colour line drawing (draft, D) | Up to 1.5 min/page |
Print time (color image ISO N5, best quality, D coated paper) | Up to 13.5 min/page min/page |
Energy Star certified | Y |
---|---|
Safety | ITE product compliance, EU LVD, CSA Certified for US and Canada, Mexico NOM-1-NYCE, Argentina IRAM, China CCC, Singapore PSB, Russia GOST, Poland PCBC, Korea KTL |
Electromagnetic compatibility | Compliant with requirements for Class B ITE products (Class A when connected to LAN cables), EU (EMC Directive), US (FCC rules), Canada (DOC), Australia (ACA), New Zealand (MoC), China (CCC), Japan (VCCI), Class A for Korea (MIC), Taiwan (BSMI) |
Print head | 4 (1 each cyan, magenta, yellow, black) |
---|---|
Print head nozzles | 304 |
Network ready | Optional |
---|---|
Embedded web server | Y |
Maximum input capacity | 100 sheets |
---|---|
Standard input capacity | 150 sheets |
Pallet dimensions (W x D x H) (imperial) | 47.2 x 43.3 x 82.6 " |
---|---|
Product dimensions when open (LxWxD) | 41 " |
Package dimensions (W x D x H) | 46.9 x 21.5 x 19.4 " |
Pallet dimensions (W x D x H) | 1200 x 110 x 2098 mm |
Package weight (imperial) | 75 lb lbs |
Maximum dimensions (W x D x H) | 1042 x 1020 x 220 mm |
Recommended operating temperature range (T-T) | 15 - 30 °C |
---|---|
Operating temperature (T-T) | 59 - 86 °F |
Interface | USB 1.1 (USB 2.0 compliant), Centronics parallel IEEE-1284 (ECP compliant), 1 EIO slot |
---|
Print time (colour image ISO N5, draft quality, D glossy paper) | Up to 14.5 min/page min/page |
---|---|
Print time (color image ISO N5, normal quality, B glossy paper) | Up to 4 min/page min/page |
Color printing technology | HP Color Layering technology |
Print time (color image ISO N5, normal quality, D glossy paper) | Up to 14.5 min/page min/page |
Print time (colour image ISO N5, normal quality, A3 glossy paper) | Up to 4 min/page min/page |
Print time (color image ISO N5, best quality, B glossy paper) | Up to 6 min/page min/page |
Print time (colour image ISO N5, best quality, A3 glossy paper) | Up to 6 min/page min/page |
Print time (colour image ISO N5, normal quality, B coated paper) | Up to 2.5 min/page min/page |
Print quality (colour, best quality) | 1200 DPI |
Print time (colour image ISO N5, best quality, D glossy paper) | Up to 21.5 min/page min/page |
