JetDirect Compatible Products | Y |
---|---|
Maximum optical density (black) | 2.5 maximum black optical density (4 L* min) with HP Premium Instant Dry Photo Gloss media |
Non-printable area (imperial cut-sheet) | 0.2 x 0.67 x 0.2 x 0.2 in |
Driver updates | Latest Windows printer drivers information available at http://windowsupdate.microsoft.com and more information on all printer drivers available at http://welcome.hp.com/country/us/en/support.html?pageDisplay=drivers |
Roll maximum input | 1 |
Printing material waterfastness | Water-resistant on a range of HP creative and speciaty papers |
Compatible ink types, supplies | HP Vivera pigment inks |
Control panel | 240 x 160 pixel greyscale graphical display with Asian fonts support, 4 direct-access buttons, 7 navigation buttons and 2 bicolour lights (Ready, Processing, Attention, Error) |
Color stability | < 1 dE2000 in less than 5 minutes |
Line width minimum | 0.0022 in |
Line accuracy | +/- 0.010 mm |
Print repeatability | Average < 0.5 dE2000, 95% of colors < 1.4 dE2000 |
Color accuracy | Median < 1.6 dE2000, 95% of colors < 2.8 dE2000 |
Package dimensions (W x D x H) | 77.3 x 30.7 x 30.7 " |
---|---|
Pallet dimensions (W x D x H) | 1965 x 780 x 780 mm |
Package weight (imperial) | 271 lb lbs |
Pallet weight (imperial) | 271 lbs |
Pallet dimensions (W x D x H) (imperial) | 77.3 x 30.7 x 30.7 " |
Product dimensions when open (LxWxD) | 69.7 " |
Maximum dimensions (W x D x H) | 1770 x 690 x 1047 mm |
Pallet weight | 123000 g |
Maximum media length (imperial) | 66 " |
---|---|
Maximum media width (imperial) | 44 " |
Media sizes standard (imperial rolls) | Letter to E-size sheets, 11 to 44-in rolls |
Maximum roll length | 91.4 m |
Maximum print length (imperial) | 300 ft; Operating system and application dependent |
Recommended media weight | 500 g/m² |
---|---|
Standard media sizes | All standard sizes larger than A4 |
Print margin cut-sheet | 5 x 17 x 5 x 5 mm |
Print margin roll | 5 mm |
Media sizes supported (imperial) | A, B, C, D, E |
Media thickness (by paper path) | Up to 31.5 mil |
Recommended media weight (imperial) | 133 lb |
Roll external diameter | 136 mm |
Non-printable area roll media (imperial) | 0.2 x 0.2 x 0.2 x 0.2 in (full bleed available on glossy/satin roll media) |
Maximum media width | 1118 mm |
Media handling | Sheet feed, roll feed, automatic cutter (cuts all media except canvas) |
Media thickness | > 0.8 mm |
Maximum print length | 91 m |
Media types supported | Photographic (satin, gloss, semi-gloss, matte), proofing (semi-gloss, high-gloss contract, semi-gloss contract, matte), fine art printing material (smooth, textured, watercolour, satin, aquarella, litho-realistic, canvas), self-adhesive (indoor, vinyl, polypropylene), banner and sign (display film, indoor banner, scrim, polypropylene, Tyvek, outdoor, billboard, PVC-free), bond and coated (bond, coated, heavyweight coated, super heavyweight plus matte, coloured), technical (tracing, translucent bond, vellum), film (clear, matte, polyester), backlit, fabric/textile (flag, polyester, silk) |
Lateral margins | 5 mm |
Media weights by paper path | 133 lb |
Maximum length of sheet media | 1676.4 mm |
Custom media sizes | 216 x 279 to 1118 x 1676 mm |
Roll bottom margin | 5 mm (borderless on glossy roll media) |
Roll left margin | 5 mm (borderless on glossy roll media) |
Roll right margin | 5 mm (borderless on glossy roll media) |
Roll top margin | 5 mm |
Margins, leading/trailing edges | Roll: 5 mm or borderless; sheet: 5 mm (top), 5 mm (right), 5 mm (left), 17 mm (bottom) |
Roll paper | Y |
Print quality (black, draft quality) | 1200 DPI |
---|---|
Printing material lightfastness | Approximately 200 years |
Ink drop | 4 pl (lc, lm, lg, pK, E, G), 6 pl (M, Y, mK, R, GN, B) |
Print resolution (colour, normal quality) | 1200 x 1200 DPI |
Printing colours | Blue, Gloss enhancer, Green, Light cyan, Light grey, Light magenta, Magenta, Matte black, Photo black, Red, Yellow |
Printer management | HP Web Jetadmin |
Print quality (colour, draft quality) | 1200 x 1200 DPI |
Print quality (black, normal quality) | 1200 DPI |
Print quality (black, best quality) | 2400 x 1200 DPI |
Minimum line width | 0.0558 mm |
Recommended operating temperature range (T-T) | 15 - 35 °C |
---|---|
Operating altitude (imperial) | 9,842 ft |
Operating temperature (T-T) | 59 - 95 °F |
Drive device, buffer size | 256 MB |
---|---|
Processor frequency | 600 MHz |
Internal memory | 256 MB |
Hard drive capacity | 80 GB |
Acoustic pressure emissions (standby) | 29 dB(A) |
---|---|
Acoustic power emissions | 6.5 B(A) (active/printing), 4.4 B(A) (standby) |
Acoustic power emissions (standby) | 4.4 B(A) B |
Embedded web server | Y |
---|---|
Network ready | Y |
Networking features | Ethernet, Fast Ethernet |
Print head nozzles | 12672 |
---|---|
Print head | 6 (magenta and yellow, light magenta and light cyan, photo black and light gray, matte black and red, gloss enhancer and gray, blue and green) |
Minimum system requirements for Macintosh | Mac OS X v10.4, v10.5: PowerPC G3 or Intel Core Processor; 256 MB RAM; 1 GB available hard disk space |
---|---|
Browser supported | Internet Explorer 5.0 and higher, Netscape 6.0.1 and higher, Safari for Mac OS 10.3 and higher, Mozilla 1.5 and higher |
Safety | IEC 60950-1 compliant, EU LVD and EN 60950-1 compliant, certified by CSA for Canada and US, Argentina IRAM, Singapore PSB, Russia GOST, China CCIB, Taiwan BSMI |
---|---|
Electromagnetic compatibility | Compliance for Class B products: EU (EMC Directive), USA (FCC rules), Canada (DoC), Australia (ACA), New Zealand (MoC), China (CCC), Japan (VCCI), Korea (MIC) and Taiwan (BSMI) |
Energy Star certified | Y |
Print speed (colour image, best quality, glossy paper) | 2.6 m2/hr\n27.8 ft2/hr |
---|---|
Print time (colour image ISO N5, normal quality, D coated paper) | 3.8 min/page min/page |
Print speed (color image, draft quality, coated paper) | 182.9 ft2/hr |
Print speed (color image, normal quality, coated paper) | 92.4 ft2/hr |
Print time (color image ISO N5, best quality, D coated paper) | 12.2 min/page min/page |
Print time (color image ISO N5, draft quality, D coated paper) | 2 min/page min/page |
Print time (color image ISO N5, normal metric A1 coated paper) | 3.8 min/page |
Downloadable software | Latest Windows printer drivers information available at http://windowsupdate.microsoft.com and more information on all printer drivers available at http://welcome.hp.com/country/us/en/support.html?pageDisplay=drivers |
---|
Interface | 1 10/100Base-T Ethernet RJ-45 port; 1 Hi-Speed USB 2.0 certified port; 1 EIO Jetdirect accessory slot |
---|
Print speed (colour image, normal quality, glossy paper) | 47.6 ft2/hr\n4.4 m2/hr |
---|---|
Print quality (colour, best quality) | 2400 DPI |
Colour management | HP Color Center, HP Vivera pigment inks, HP embedded spectrophotometer |
Print time (color image ISO N5, normal quality, D glossy paper) | 7.2 min/page min/page |
Print time (colour image ISO N5, best quality, metric A1 glossy paper) | 12.4 min/page |
Print time (colour image ISO N5, best quality, D glossy paper) | 12.4 min/page min/page |
Print time (color image ISO N5, draft quality, A1 coated paper) | 2 min/page |
Designjet model size (metric) | 111.8 cm |
Print time (color image ISO N5, normal metric A1 glossy paper) | 7.2 min/page |
