Networking
| Cabling technology |
10/100Base-T(X), 100Base-F(X), 100Base-S(X) |
Other features
| Fiber type |
9/125 µm |
| Power budget |
21 dB |
| Full duplex |
Y |
| Interface |
RJ-45, ST (2.5mm) |
| Compliance industry standards |
IEEE 802.3i, IEEE 802.3u |
| Operating temperature (T-T) |
32 - 122 °F |
Performance
| Maximum transfer distance |
40000 m |
| Wavelength |
1310 nm |
Operational conditions
| Operating altitude |
0 - 3048 m |
Additionally
| Transfer rate (Mbps) |
100 Mbit/s |
| Wireless technologies |
Wired |
iMcV-LIM, TX/FX-SM1310/PLUS-ST, 100Mb/s, 40km
Manageable 100 Mbps UTP to Fiber Media Converter Module
Modular iMcV-LIM SNMP-manageable media converters deliver a value priced conversion solution, up to Fast Ethernet speeds. iMcV-LIM series converters are ideal in all premises LAN, fiber distance extension and service provider applications. For example, LAN managers can use these converters to interconnect workgroup switches over fiber optics. Service providers can deploy iMcV-LIM converters back-to-back to provide high-speed data connections to business customers.
iMcV-LIM 100 - iMcV-LIM 100 SNMP-manageable converters perform a fixed rate UTP to fiber media conversion between 100Base-TX and 100Base-SX or FX.
iMcV-LIM series converters support multi-mode, single-mode, single-strand and CWDM fiber types with ST or SC connectors. Additionally, the iMcV-LIM 100 supports Config Control, a feature that retains the latest configuration on the module regardless of how the initial configuration was setup; whether through DIP Switch settings or the SNMP Management Module's configuration. This feature is beneficial when:
- changing the settings of a currently installed iMcV-Module through iView2;
- replacing the same type of iMcV-Module;
- installing a new or different type of iMcV-Module.
iMcV-LIM series modules are easy to configure and manage with IMC Networks' iView2 SNMP management application, or with any other SNMP application such as HP OpenView™. iView2 software features an easy-to-use and intuitive Graphical User Interface (GUI) that enables the configuring, monitoring and managing of installed media modules from a central location. Via iView2, network managers can receive real-time unit and port status information, as well as configure individual modules for various features and settings.
iView2 also includes automatic updates for software and device firmware, and event/trap management for IMC Networks' and other manufacturers' devices installed in the network. iView2 runs standalone on Windows NT/XP/2000/Vista; as a standalone Java Application for other operating systems; as a plug-in module for HP OpenView; as a Web Server running under IIS or as a Java Web Servlet.
iMcV-LIM modules install in managed iMediaChassis and unmanaged MediaChassis.
Features:
- Includes LinkLoss and FiberAlert feature for cabling troubleshooting;
- Automatic MDI/MDIX;
- Supports Config Control;
- Features Link Fault Pass-Through (LFPT);
- Supports GUI-based iView2;
- Includes diagnostic and status LEDs.
