Design
| Motherboard form factor |
UCFF |
| LED indicators |
Power |
| Cable lock slot |
Y |
| Cable lock slot type |
Kensington |
Memory
| Supported memory clock speeds |
1600, 1866 MHz |
| Memory bandwidth (max) |
14.9 GB/s |
| ECC |
N |
| Supported memory types |
DDR3L-SDRAM |
| Memory voltage |
1.35 V |
| Memory channels |
Dual |
| Memory slots type |
SO-DIMM |
| Number of memory slots |
2 |
| Maximum internal memory |
8 GB |
Performance
| BIOS memory size |
64 MB |
| BIOS type |
EEPROM |
| Trusted Platform Module (TPM) |
N |
| Intel Visual BIOS |
Y |
| Intel Express BIOS update |
Y |
| Number of displays supported |
2 |
Storage
| Storage drive sizes supported |
2.5 " |
| Number of storage drives supported |
1 |
| Supported storage drive types |
HDD, SSD |
| Compatible memory cards |
SDXC |
| Card reader integrated |
Y |
Motherboard
| Number of processors supported |
1 |
Processor
| Processor boost frequency |
2.30 GHz |
| Processor lithography |
14 nm |
| Thermal Design Power (TDP) |
10 W |
| L3 cache |
2 MB |
| Processor cores |
4 |
| Built-in processor |
Y |
| Processor frequency |
1.50 GHz |
Processor special features
| Intel Rapid Storage Technology |
N |
| Execute Disable Bit |
Y |
| Idle States |
Y |
| Thermal Monitoring Technologies |
Y |
| Intel Trusted Execution Technology |
N |
| Intel Smart Connect Technology |
N |
| Intel® Small Business Advantage (Intel® SBA) |
N |
| Intel Stable Image Platform Program (SIPP) |
N |
| Intel® Quick Sync Video Technology |
Y |
| Intel® Insider™ |
N |
| Intel 64 |
Y |
| Intel Clear Video Technology |
Y |
| Intel® Smart Response Technology |
N |
| Embedded options available |
N |
| Intel Virtualization Technology for Directed I/O (VT-d) |
Y |
| Intel® Anti-Theft Technology (Intel® AT) |
N |
| Intel® Identity Protection Technology (Intel® IPT) |
Y |
| Intel Hyper-Threading Technology |
N |
| Intel® Turbo Boost Technology |
N |
| Intel® Secure Key |
Y |
| Intel® Virtualization Technology (Intel® VT) |
VT-x |
| Intel vPro Technology |
N |
| Intel VT-x with Extended Page Tables (EPT) |
Y |
| Enhanced Intel SpeedStep Technology |
Y |
| Intel® OS Guard |
N |
| Intel® Wireless Display (Intel® WiDi) |
N |
| Intel® Clear Video HD Technology (Intel® CVT HD) |
Y |
Graphics
| On-board graphics adapter |
Y |
| Graphics adapter family |
Intel |
Ports & interfaces
| Combo headphone/mic port |
Y |
| Number of SATA III connectors |
1 |
| S/PDIF out port |
Y |
| Internal USB 2.0 ports quantity |
2 |
| USB 3.0 (3.1 Gen 1) Type-A ports quantity |
4 |
| Consumer infrared headers |
Y |
| HDMI ports quantity |
1 |
| VGA (D-Sub) ports quantity |
1 |
Audio
| Audio output channels |
7.1 channels |
| Audio system |
Realtek ALC283 |
Networking
| Bluetooth version |
4.2 |
| Wi-Fi |
Y |
| Wi-Fi standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Bluetooth |
Y |
Expansion slots
| PCI Express slots version |
2.0 |
Power
| Power supply |
65 W |
| AC adapter output voltage |
12-19 V |
| Power supply type |
External AC adapter |
Additionally
| InTru™ 3D Technology |
N |
| Intel HD Audio Technology |
Y |
| Graphics |
HD Graphics 500 |
| Ethernet LAN connection |
Y |
| On/Off switch |
Y |
| Intel AES New Instructions |
Y |
| AC adapter bundled |
Y |
| Ethernet LAN (RJ-45) ports quantity |
1 |
Intel® NUC Kit NUC6CAYH built with a quad-core Intel® Celeron® processor, delivers cost-efficient Intel-level performance in a fully customizable kit that makes it perfect for basic 4K digital signage, PC replacement, or thin client. This kit gives you the choice to install the OS, memory, and hard drive you want so you can create the exact system that you need. New features include a dual-array front mic and a multi-color LED ring so you can customize your NUC with the look you want. And there’s 4K display support via a full-sized HDMI 2.0 port, so you can have 4K digital signs at a cost-effective price point.
