Performance
| Wavelength |
1300 nm |
| Sensitivity |
-31 dBmW |
| Tx power (min) |
-20 dBmW |
| Maximum transfer distance |
2000 m |
| Fiber mode structure |
Multi-mode |
| Tx power (max) |
-14 dBmW |
Other features
| Full duplex |
Y |
| Operating temperature (T-T) |
32 - 122 °F |
Ports & interfaces
| Fiber ports quantity |
1 |
| DC-in jack |
Y |
Additionally
| Transfer rate (Mbps) |
100 Mbit/s |
| Ethernet LAN (RJ-45) ports quantity |
1 |
| Wireless technologies |
Wired |
IEEE 802.3/802.3u, 100Base TX/FX, RJ-45, duplex port, black
Data transfer rate: 100 Mbps
One 10/100Base-TX RJ-45 Port, maximum distance 100 m / 300 ft
RJ-45 port with Auto MDI/MDI-X support and auto-negotiation
One 100Base-FX Multi-Mode fiber ST duplex port
Fiber distance support: up to 2 km / 1.24 mi (62.5/125 or 50/125 µm cable)
Status LEDs for easy monitoring of device status
Link Fault Signaling (LFS)
Remote and local loop back test
DIP switches for multiple configuration options
External power adapter
Can be used stand-alone or in INTELLINET NETWORK SOLUTIONS converter chassis model 519151 (12 Port)
Lifetime Warranty
