Projector
| Service life of lamp |
4000 h |
| Zoom capability |
2x |
| Projection technology |
D-ILA |
| Lamp type |
NSH |
| Focal length range (f-f) |
21.4 - 42.8 mm |
1.778 cm (0.7 ") Full HD 1920 x 1080 D-ILA x 3, NSH 230W, 1300 lm, 21 dB, 100 - 240V, 50/ 60Hz
JVC's D-ILA 4K projector with high native contrast ratio of 60,000:1*, and maximum Dynamic contrast ratio of 600,000:1 achieved by adopting an optical engine with new wire grid and the latest 6th generation original D-ILA device. Additionally, e-shift 3 Technology with enhanced Multiple Pixel Control image processor and analyser achieves a high-definition 4K image optimal for a variety of scenes.
- New 6th generation 0.7" Full HD D-ILA devices x 3
- 4K resolution (3840 x 2160) achieved with e-shift 3 Technology including Multiple Pixel Control image processor
- 4K signal input (50p/60p compatible with 4:2:0 colour base)
- Resolution: 3840 x 2160 (in 2D); 1920 x 1080 (in 3D)
- NSH 230W
- Connectors: HDMI x 2 (3D, Deep Colour, CEC compatible), RS-232C x 1, LAN x 1, Trigger x 1, 3D x 1
- 4K Projection (3840 x 2160 pixels) achieved with optical engine featuring e-shift 3 Technology with Multiple Pixel Control image processor and MPC analyser
- Dynamic contrast ratio of 600,000:1 (max.) and Native contrast ratio of 60,000:1 achieved with original D-ILA device and an optical engine equipped with new wire grid
- Brightness of 1300 lumens
- Improved 3D viewing with reduced crosstalk made possible by D-ILA's original Frame Addressing driver technology
- An array of 3D picture adjustment functions: 2D-3D conversion, Crosstalk Cancelling, Disparity Adjustment, and Depth Adjustment
- Wireless transmission options for 3D viewing: RF (radio frequency) system transmission with PK-AG3 3D Glasses for 100H continuous operation and PK-EM2 3D Synchro Emitter
- Colour Management System with 7-axis Matrix
- Clear Motion Drive 3 improves pictures with rapid movement for both 4K and 3D images
- Pixel Adjust function allows user to precisely correct colour deviation in 1/16-pixel increments; also segments the screen into 121 points for individual adjustment. Two customized settings can be stored in the memory.
- Environmental Setting automatically adjusts images to best match the environment
- Screen Adjustment Mode: 106 modes (Up to 255 modes)
- Intelligent Lens Aperture
- Lens Memory function (5 memories)
- Digital Keystone in 2D mode (vertical direction)
- Projector can be easily controlled from a smartphone or tablet
