Other features
| Supported data transfer rates |
300, 108, 54, 48, 36, 24, 18, 12, 11, 9, 6, 5.5, 2, 1 Mbps |
| Connectivity LEDs |
Y |
| Non-operating relative humidity (non-condensing) |
0 - 95% |
| Wireless technology |
WiFi |
| Outdoor range |
150m |
| Compliance industry standards |
802.3af, 802.11a/b/g/h/n |
| Networking features |
Ethernet, Fast Ethernet, Gigabit Ethernet |
Security
| Authentication method |
EAP-TLS, EAP-TTLS, PEAP, MS-CHAP, MS-CHAPv2, PAP, CHAP |
| MAC address filtering |
Y |
Ports & interfaces
| Cabling technology |
10/100/1000 Base-TX |
| WAN connection |
Ethernet (RJ-45) |
| DC-in jack |
Y |
Performance
| Receiver sensitivity |
2.4 GHz:\n- 802.11b: -91 dBm @ 11 Mbps, -93 dBm @ 1 Mbps, 802.11g:, -94dBm @ 6 Mbps, -80dBm @ 54 Mbps\n-802.11n: -94 dBm @ 6,5 Mbps (MCS0, 20 MHz), -77 dBm @ 65 Mbps (MCS7, 20 MHz), -94 dBm @ 13 Mbps (MCS 8, 20 MHz), -77 dBm @ 130 Mbps (MCS15, 20 MHz), -89 dBm @ 15 Mbps (MCS0, 40 MHz), -73 dBm @ 150 Mbps (MCS7, 40 MHz), -89 dBm @ 30 Mbps (MCS8, 40 MHz), -73 dBm @ 300 Mbps (MCS15, 40 MHz)\n5 GHz:\n- 802.11a/h: -94 dBm @ 6 Mbps, -77 dBm @ 54 Mbps\n- 802.11n: -93 dBm @ 6,5 Mbps (MCS0, 20 MHz), -74 dBm @65 Mbps (MCS7, 20 MHz), -93 dBm @ 13 Mbps (MCS8, 20 MHz), -74 dBm @ 130 Mbps (MCS15, 20 MHz), -90 dBm @ 15 Mbps (MCS0, 40 MHz), -72 dBm @ 150 Mbps (MCS7, 40 MHz), -90 dBm @ 30 Mbps (MCS8, 40 MHz), -72 dBm @ 300 Mbps (MCS15, 40 MHz) |
| VLAN support |
Y |
| 2.4 GHz |
Y |
| Quality of Service (QoS) support |
Y |
| Frequency band |
2.4 - 2.4835, 5.15 - 5.825 GHz |
| Ethernet LAN data rates |
1000 Mbit/s |
| Channels quantity |
13 channels |
Protocols
| Management protocols |
SNMP, SYSLOG |
| DHCP client |
Y |
| DHCP server |
Y |
| Supported network protocols |
PPPoE, Multi-PPPoE, ML-PPP, PPTP (PAC/PNS), RIP- 1, RIP-2, VLAN, IP |
Power
| Power over Ethernet (PoE) |
Y |
Additionally
| Indoors max range |
30m |
| Transfer rate (Mbps) |
300 Mbit/s |
L-320agn - Wireless Access Point for highly discreet WLAN installations
The LANCOM L-320agn Wireless is a 802.11n dual band access point with an integrated MIMO antenna which operates either in the 2.4 or 5-GHz band. It is ideally suited for
places where external antennas should be avoided to prevent theft, for example in locations such as hospitals, schools or hotels. As this access point features 802.3af Power over
Ethernet, it can even be installed if no wall sockets are available.
More Performance
The 802.11n standard includes several mechanisms such as MIMO, 40 MHz channels, packet aggregation, and block acknowledgement which significantly increase the amount of
bandwidth available for user applications. With throughput rates up to 300 Mbps, this represents a greater than five- fold increase over the performance of 802.11a/g networks.
Better and Reliable Coverage
MIMO technology uses multiple antennas at both the transmitter and receiver to transmit multiple spatial streams. The multiple transmit streams which take different routes in
reflecting environments are combined at the receiver using MIMO techniques. The end result is a two- fold increase in throughput and improved wireless coverage due to lesser
deadspots.
More Security
LANCOM sets the standards in WLAN security. A comprehensive range of security technologies is supported in wireless LAN including IEEE 802.11i, 802.1x, WPA, WPA2, WEP64/
128/152, access control lists or LEPS (LANCOM Enhanced Passphrase Security), which enables the configuration of an optimized solution, whatever the individual requirements.
For example, Multi SSID allows the definition of up to 8 user groups, each with its own level of security.
More Management
LANCOM’s WLAN management tools offer real benefits to network administrators for the installation, control and monitoring of access points. LANCOM WLAN Controller has builtin
support for the L- 3xx access point. LANCOM's "Smart Controller" architecture is specifically designed to support high bandwidth applications by providing flexible data plane
switching options. As a result higher bandwidth applications can directly offloaded at the access point and reduces the overall cost involved in expensive network upgrades required
in centralized architectures. WLANmonitor visualizes the devices connected to WLAN irrespective of physical location and facilitates the central surveillance of the entire wireless
network.
More Reliability for the Future
From the very start, LANCOM products are designed for a product life of several years. They are equipped with hardware dimensioned for the future. Even reaching back to older
product generations, updates to the LANCOM Operating System–LCOS–are available several times a year, free of charge and offering major features. LANCOM offers unbeatable
protection of your investment!
