Processor
| Maximum internal memory supported by processor |
288 GB |
| Processor frequency |
2.26 GHz |
| Processor cores |
4 |
| Stepping |
B1 |
| Processor operating modes |
64-bit |
| Embedded options available |
N |
| FSB Parity |
N |
| Processor front side bus |
1066 MHz |
| Conflict Free processor |
N |
| Memory bandwidth supported by processor (max) |
25.6 GB/s |
| Processor cache type |
Smart Cache |
| Processor code |
SLBZ9 |
| Physical Address Extension (PAE) |
40 bit |
| Thermal Design Power (TDP) |
80 W |
| CPU multiplier (bus/core ratio) |
17 |
| Processor package size |
42.5 mm |
| Thermal Monitoring Technologies |
N |
| Execute Disable Bit |
Y |
| Number of QPI links |
2 |
| Processor cache |
8 MB |
| Number of processors installed |
1 |
| Maximum number of SMP processors |
2 |
| Processor lithography |
32 nm |
| Bus type |
QPI |
| Supported instruction sets |
SSE4.2 |
| ECC supported by processor |
Y |
Processor special features
| Intel Clear Video Technology for MID |
N |
| Intel® My WiFi Technology (Intel® MWT) |
N |
| Intel Enhanced Halt State |
Y |
| Intel Hyper-Threading Technology |
N |
| Intel® Anti-Theft Technology (Intel® AT) |
N |
| Intel Virtualization Technology for Directed I/O (VT-d) |
Y |
| CPU configuration (max) |
2 |
| Intel Dual Display Capable Technology |
N |
| Intel Clear Video Technology |
N |
| Intel 64 |
Y |
| Intel® Insider™ |
N |
| Intel® Quick Sync Video Technology |
N |
| Processor ARK ID |
52582 |
| Intel® Turbo Boost Technology |
N |
| Intel Trusted Execution Technology |
Y |
| Intel Flex Memory Access |
N |
| Intel Fast Memory Access |
N |
| Intel Rapid Storage Technology |
N |
| Intel® Clear Video HD Technology (Intel® CVT HD) |
N |
| Intel® Wireless Display (Intel® WiDi) |
N |
| Intel Demand Based Switching |
Y |
| Enhanced Intel SpeedStep Technology |
Y |
| Intel FDI Technology |
N |
| Intel VT-x with Extended Page Tables (EPT) |
Y |
| Intel vPro Technology |
N |
Storage
| RAID support |
Y |
| Maximum storage capacity |
16 TB |
| Number of hard drives supported |
8 |
| Hot-swap |
Y |
| Hard drive size |
3.5 " |
Memory
| Maximum internal memory |
128 GB |
| Memory slots |
16 x DIMM |
| Memory clock speed |
1066 MHz |
| ECC |
Y |
| Internal memory |
2 GB |
| Internal memory type |
DDR3-SDRAM |
Other features
| Mac compatibility |
N |
| Graphics adapter family |
Matrox |
| Half-height bay note |
"_rotate_category_feature_id_30301=30301 |
Power
| Number of power supply units |
1 |
| Power supply |
670 W |
Networking
| LAN controller |
Broadcom BCM5716 |
| Wake-on-LAN ready |
Y |
| Networking features |
Gigabit Ethernet |
Expansion slots
| PCI Express x8 slots |
4 |
| PCI Express x16 slots |
1 |
| PCI slots |
1 |
Design
| Chassis type |
Tower (5U) |
| Optical drive type |
DVD-ROM |
Graphics
| Maximum graphics adapter memory |
16 MB |
Ports & interfaces
| Serial ports quantity |
1 |
| VGA (D-Sub) ports quantity |
1 |
Operational conditions
| Operating altitude |
0 - 2133 m |
Certificates
| Compliance industry standards |
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab |
| Energy Star certified |
Y |
Additionally
| System bus data transfer rate |
4.8 GT/s |
| Chipset |
Intel 5520 |
| InTru™ 3D Technology |
N |
| Ethernet LAN (RJ-45) ports quantity |
3 |
| Intel AES New Instructions |
Y |
| Ethernet LAN connection |
Y |
| Graphics |
G200eV |
x3400 M3, Intel Xeon E5607 (8M Cache, 2.26 GHz, 4.80 GT/s Intel QPI), 2GB DDR3, 4 x 3.5" SATA HDD, Simple-Swap, 4 x 3.5 SAS/SATA HDD, Hot-Swap, DVD-ROM, 2 x RJ-45, Gigabit Ethernet, 6 x USB 2.0, Tower/5U
Highlights
- Provides optimum performance and processing capability at a lower cost.
- Offers large storage capacity and flexible configurations to scale as needs grow.
- Helps reduce energy costs and ease management with efficient design.
Achieve IT goals with a sustainable investment
The IBM System x3400 M3 tower server with the latest Intel ® Xeon® processors offers flexibility, reliability and security as well as enhanced systems management features that make it an ideal choice for small, midsize and distributed businesses. This 2-socket server provides a balance of performance, high availability, expansion capability and ease of management in a stable, long-life platform. The x3400 M3 includes features designed to achieve affordable performance on a tower server, allowing you to replace your older systems as business grows.
Grow affordably with flexible upgrades
The x3400 M3 offers flexible configuration options to help you scale easily as business grows. Higher storage capacity as well as choice in storage interface lets you transform your business as you require. Select the right combination of hard disk drive size, processor and memory capacity for today, and easily incorporate more tomorrow.
Product features
- Dual-socket computing power optimized for up to 8 total cores standard or up to 12 cores (configure to order only) at lower power usage per core.
- Greater memory and storage capacity than previous generations.
- Cost-saving design to help achieve data center like computing power at desk-side infrastructure price point.
- Optional hot-swap hard disk drives and performance-optimized RAID support.
- Mainframe-inspired reliability and quality for maximum uptime.
- Energy-efficient design and IBM Systems Director Active Energy Manager™ to save electricity and cooling costs, and reduce noise.
- Comprehensive systems management.
- Support legacy PCI slots for smooth transition.
Hardware summary
- 5U tower with optional rack-mount capability.
- Up to two four-core Intel Xeon E5620 2.40 GHz processors with 12 MB optimized cache standard or up to two six-core Intel Xeon X5675 3.06 GHz processors with 12 MB optimized cache (configure to order only).
- 1333 MHz, DDR-3 registered DIMM memory.
- Up to five high-performance PCIe I/0 slots and one PCI slot standard, additional two PCI-X or one PCIe available via configure to order only.
- Supports up to eight or 16 small form factor (2.5") hot-swap Serial Attached SCSI (SAS) or Serial ATA (SATA) hard disk drives (HDDs) (model dependent); or up to four 3.5" simple-swap SATA HDDs or up to eight 3.5" hot-swap SAS or SATA HDDs (configure to order only).
- 6 Gbps RAID and 3 Gbps adapters standard (model dependent).
