Ports & interfaces
| DC-in jack |
Y |
| DisplayPorts quantity |
1 |
| VGA (D-Sub) ports quantity |
1 |
| Microphone in |
Y |
| PS/2 ports quantity |
2 |
| Serial ports quantity |
4 |
| Parallel ports quantity |
1 |
| Headphone outputs |
1 |
Networking
| Wi-Fi |
N |
| Bluetooth |
N |
| Wake-on-LAN ready |
Y |
Processor
| Processor frequency |
1.5 GHz |
| L3 cache |
1.5 MB |
| Processor cores |
1 |
Storage
| Card reader integrated |
N |
| Total storage capacity |
1 GB |
| Storage media |
Flash |
Design
| Cable lock slot |
Kensington |
Memory
| Memory slots |
1x SO-DIMM |
| Internal memory |
2 GB |
| Internal memory type |
DDR3-SDRAM |
| Maximum internal memory |
4 GB |
| Memory clock speed |
1600 MHz |
Weight & dimensions
| Depth (without stand) |
170 mm |
| Width (without stand) |
55 mm |
| Height (without stand) |
220 mm |
Additionally
| Ethernet LAN connection |
Y |
| Chipset |
Intel NM70 Express |
| Ethernet LAN (RJ-45) ports quantity |
1 |
Intel Celeron 807, 2 GB DDR3 1600 MHz, 1 GB ROM, USB 2.0, PS/2, VGA, Display-Port, Intel HD Graphics, LeTOS
<b>Fan-Less, Cable-Less Design</b>
Whisper-quiet and designed for lower power consumption, M32 meets Energy Star 5.2 certification and promises high efficiency, energy savings, and long life.
<b>Lenovo Thin Client Manager on Server</b>
This web-based application gives administrators the ability to access the console from any terminal, and to manage Thin Clients individually or as a group. Delivered as a virtual appliance, LTM is easy to install, user-friendly, and intuitive.
<b>Variety of I/O Support</b>
No matter your legacy port needs, M32 has you covered, with support for USB 2.0, VGA out, DP out, COM, Parallel, PS/2 – plus customizable pin definition on your COM port design.
<b>Dual Display Support</b>
Connect two monitors, using either a VGA port or a DisplayPort – save on the cost of an additional graphics card.
<b>Security Lock</b>
After deployment, keep each of your ultra-small PCs where it belongs with a Kensington Security Lock.
<b>Multiple Virtualization Management App Certifications</b>
M32 is compatible with Citrix® Receiver, VMWare® View and Microsoft Remote FX, for better manageability.
