Data transmission
| MAC address table |
8192 entries |
| Store-and-forward |
Y |
| Switching capacity |
48 Gbit/s |
| Jumbo frames |
9000 |
| Packet forwarding rate (1 Gbps) |
1488000 pps |
| Packet forwarding rate (10 Mbps) |
14880 pps |
| Packet forwarding rate (100 Mbps) |
148000 pps |
Management features
| ARP inspection |
Y |
| System event log |
Y |
| Quality of Service (QoS) support |
Y |
| Reset button |
Y |
| Web-based management |
Y |
Networking
| Port mirroring |
Y |
| VLAN support |
Y |
| Auto MDI/MDI-X |
Y |
| Tagged VLAN |
Y |
| Rate limiting |
Y |
| Link aggregation |
Y |
| Active link detection |
Y |
| MAC address auto-learning supported |
Y |
| MAC address auto-aging supported |
Y |
| Port-based VLAN |
Y |
| Flow control support |
Y |
| Full duplex |
Y |
| DHCP client |
Y |
| 10G support |
N |
Security
| Static port security |
Y |
| Loop protection |
Y |
| BPDU filtering/protection |
Y |
| Auto-edge port |
Y |
| MAC address filtering |
Y |
Ports & interfaces
| Basic switching RJ-45 Ethernet ports quantity |
8 |
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| Copper ethernet cabling technology |
100BASE-TX, 1000BASE-T, 10BASE-T |
| Console port |
RS-232 |
| SFP module slots quantity |
16 |
Performance
| Packet buffer memory |
4 MB |
| Internal memory |
32 MB |
| Firmware upgradeable |
Y |
| Auto-negotiation |
Y |
Packaging data
| Mounting brackets included |
Y |
| Resource CD |
Y |
| Quick start guide |
Y |
Power over Ethernet (PoE)
| Power over Ethernet (PoE) |
N |
8x 10/100/1000Base-T RJ-45, 16x 100/1000Base-X SFP, 8192 MAC, QoS, 9K Jumbo Frame
GEL-2461 is a 24-Port Web Smart Gigabit Switch, providing secure and intelligent edge connectivity. The device is a Layer 2 wire-speed Ethernet switch, perfect for deployments in small and medium businesses, branch offices, and for running essential business services.
GEL-2461 offers 8 x 10/100/1000M auto-negotiation ports and 16 SFP combo ports. All RJ-45 ports support auto MDI/MDI-X, with SNMP and Full/Half duplex transfer mode for 10 and 100Mbps ports as well as Full duplex transfer mode for 1000Mbps ports. Supports Jumbo frame, MAC address auto-learning and a host of other features such as security logs and detailed traffic statistics for each port.
- IEEE 802.1d/w Spanning Tree Protocol (STP) and port mirroring
- 8 Gigabit Ethernet ports and 16 Gigabit SFP slots
- Supports port-based VLAN, IEEE 802.1Q VLAN Tagging
- IEEE 802.3ad LACP for auto port aggregation
- Supports Command Line Interface (in RS-232 Console)
