Security
| Firewall security |
SPI |
| Authentication method |
Radius |
Networking
| Receiver sensitivity |
802.11n HT40/MCS15 270 Mbps: -67 dBm 10%,\n802.11n HT40/MCS0 13.5 Mbps: -75 dBm 10%, 802.11n HT20/MCS15 130 Mbps: -69 dBm 10%,\n802.11n HT20/MCS0 6.5 Mbps: -79 dBm 10%,\n802.11g 54 Mbps: -74 dBm 10%,\n802.11g 6 Mbps: -84 dBm 10%,\n802.11b 11 Mbps: -86 dBm 10%,\n802.11b 1 Mbps: -92 dBm 10% |
Management features
| Universal Plug and Play (UPnP) |
Y |
| Reset button |
Y |
Ethernet LAN features
| Ethernet LAN interface type |
Fast Ethernet |
| Ethernet LAN data rates |
10, 100 Mbit/s |
Other features
| xDSL connection |
N |
| Interface |
RJ-45 |
| Bandwidth |
2.4 GHz |
| USB ports quantity |
4 |
Antenna
| Antenna gain level (max) |
1.8 dBi |
| Antenna connector type |
RP-SMA |
| Antennas quantity |
2 |
Protocols
| Supported network protocols |
TCP/IP |
Additionally
| Ethernet LAN connection |
Y |
| Ethernet LAN (RJ-45) ports quantity |
4 |
WRT160NL Wireless-N Broadband Router Storage Link
The speed and bandwidth of Wireless-N, today’s most advanced wireless technology, makes it easy for multiple users to share Internet access, files and printing. Enjoy media-intensive activities like gaming, video and Voice-over-IP phone calls – all at once, with less lag and performance degradation. Achieves faster speeds when used with Wireless-N enabled devices, but is fully compatible with Wireless-G and -B equipment.
Reliable Coverage
Experience coverage you can count on, all around your home. Wireless-N’s Multiple in, Multiple Out MIMO technology actually uses the signal reflections that confuse ordinary wireless technologies to boost range and reduce dead spots.
Storage for All
The Storage Link feature lets you connect a hard drive or flash-based USB storage device directly to your network to easily add gigabytes of storage. Access your music, video, or data files from anywhere within your network. Built-in DLNA 1.5 compatible media server streams to PCs or UPnP AV digital media adapters.
Connect to More
Four 10/100 Ethernet ports let you connect printers, networked storage drives, and other Ethernet-enabled devices to your network, so you can access and share them from all around the house.
