Other features
Data link protocols |
Tx, Rx, DTR, DSR, RTS, CTS, DCD, GND (RJ45) |
Interface |
RS-232/RS-422/485 |
Performance
Maximum transfer distance |
1200 m |
Additionally
Wireless technologies |
Wired |
Transio A53 - RS-232 to RS-422/485 Converter
Transio A53 is a smart RS-232 to RS-422/485 bi-directional converter that comes with all of the great technical specs that Moxa is well known for. This includes data direction control built into the hardware for both RS-422 and RS-485 interfaces, LED indicators for power and signal states, and surge protection and isolation protection. These last two features take care of some of the major problems faced by serial communication connections in industrial environments.
Serial Connection Problems in Industrial Environments
Serial communication and reliability can be adversely affected in a hazardous industrial environment. The wiring associated with serial communication devices could be surrounded by power lines, motors, or equipment that produces static electricity. If this is the case, the serial devices could be damaged by sudden surge waves produced by this type of equipment. In this situation, surge protection that uses TVSS (Transient Voltage Surge Supression) is the solution.
When two serial devices are directly connected, but separated by a long distance, the unbalanced ground voltage could cause serious damage. Unbalanced ground voltage between two serial ports forms a "ground loop," introducing a large current between the two pieces of serial equipment. In fact, the current could be so lare as to damage the equipment beyond repair. In this situation, the solution is to use Isolation Protection to completely isolate both communication ports.
Features:
- ADDC™ (Automatic Data Direction Control) RS-485 data control
- Auto baudrate sensing
- RS-422 hardware flow control: CTS, RTS signals
- LED indicators for power and signal states
- RS-485 multidrop operation, up to 32 nodes
- Surge protection, 25 KV ESD
- 2 KV isolation protection (A53)
- Built-in 120 Ω termination resistors
