Software
Pre-installed software |
Windows Embedded Standard 2009 |
Operating system architecture |
32-bit |
Processor
Thermal Design Power (TDP) |
2.5 W |
Conflict Free processor |
N |
Tjunction |
90 °C |
FSB Parity |
N |
CPU multiplier (bus/core ratio) |
12 |
Processor operating modes |
32-bit |
Processor socket |
Socket F (1207) |
Stepping |
C0 |
Processor cores |
1 |
Processor frequency |
1.6 GHz |
Bus type |
FSB |
Processor front side bus |
533 MHz |
Processor cache type |
L2 |
Number of Processing Die Transistors |
47 M |
Number of processors installed |
1 |
Processor cache |
0.512 MB |
Processor lithography |
45 nm |
Processor special features
Processor package size |
22 mm |
Processor ARK ID |
36331 |
Intel 64 |
N |
Embedded options available |
Y |
Intel Virtualization Technology for Directed I/O (VT-d) |
N |
Intel Hyper-Threading Technology |
Y |
Intel® Turbo Boost Technology |
N |
Intel Enhanced Halt State |
N |
Enhanced Intel SpeedStep Technology |
Y |
Intel Demand Based Switching |
N |
Supported instruction sets |
SSE3, SSE2 |
Execute Disable Bit |
Y |
Thermal Monitoring Technologies |
Y |
Intel Trusted Execution Technology |
N |
Processor code |
SLB73 |
Networking
Ethernet LAN data rates |
10, 100 Mbit/s |
Supported protocols |
DHCP, DNS, FTP, HTTP, SNTP, NTP, Telnet, SMTP, SNMPv2, TCP, UDP, IPv4, ICMP, IGMP, IPsec, TAPI, ICS, PPP, CHAP, EAP, PPPoE, PPTP, NetBIOS |
Cabling technology |
10/100Base-T(X) |
Memory
Memory clock speed |
533 MHz |
Memory layout (slots x size) |
1 x 2 GB |
Memory slots |
1x SO-DIMM |
Maximum internal memory |
2 GB |
Internal memory |
1 GB |
Internal memory type |
DDR2-SDRAM |
Packaging content
Drivers included |
Y |
Display included |
N |
Graphics
Discrete graphics adapter model |
Not available |
Ports & interfaces
RS‐232/422 port |
Y |
PS/2 ports quantity |
1 |
Line-in |
Y |
Line-out |
Y |
VGA (D-Sub) ports quantity |
1 |
DVI port |
Y |
Power
Power supply input voltage |
12 - 48 V |
Power supply |
26 W |
Storage
Total storage capacity |
2 GB |
Card reader integrated |
Y |
Hard drive interface |
Serial ATA II |
Number of storage drives supported |
1 |
Performance
Watch Dog function |
Y |
Motherboard southbridge |
Intel ICH7M |
Additionally
Chipset |
Intel 945GSE Express |
Ethernet LAN connection |
Y |
Processing die size |
26 mm² |
x86 ready-to-run embedded computer with Intel Atom N270 CPU, VGA, DVI-I, audio, 2 Ethernet LAN ports, 4 serial ports, 6 DIs, 2 DOs, 3 USB 2.0 ports, 1 CompactFlash slot, Windows Embedded Standard 2009, -25 to 60°C operating temperature (EN 50155 Class T1)
The V2406 Series embedded computers are based on the Intel Atom N270 x86 processor, and feature 4 RS-232/422/485 serial ports, dual LAN ports, and 3 USB 2.0 ports. V2406 computers provide VGA and DVI-I outputs, and in addition are compliant with a portion of EN 50155 specifications, covering operating temperature, power input voltage, power surges, ESD, and vibration, making them particularly well-suited for railway and industrial applications.
The dual 10/100 Mbps Ethernet ports with M12 connectors offer a reliable solution for network redundancy, promising continuous operation for data communication and management. As an added convenience, the V2406 computers have 6 DIs and 2 DOs for connecting digital input/output devices, and the CompactFlash feature provides the reliability needed for industrial applications that require data buffering and storage expansion.
Pre-installed with a customized version of Debian Linux 5.0 ("Lenny"), Windows Embedded Standard 2009, or Windows Embedded Standard 7, the V2406 Series provides programmers with a friendly environment for developing sophisticated, bug-free application software at a low cost. Wide temperature models of the V2406 Series that operate reliably in a -40 to 70°C operating temperature range are also available, offering an optimal solution for applications subjected to harsh environments.
