Performance
| Motherboard form factor |
Micro ATX |
Processor
| Processor system buses supported |
800 MHz |
Memory
| Maximum internal memory |
2 GB |
Expansion slots
| Expansion slots |
1x AGP 8x/4X \n2x PCI 2.2 32-bit PCI |
Networking
| Networking features |
Fast Ethernet 10/100 Mb/s |
MSI PM8M2-V Micro-ATX, VIA, P4M800, 800 MHz FSB, 2Gb memory max, 8x AGP, LAN
CPU
Supports Intel® Pentium 4 / Celeron D processors in LGA775 package.
Supports up to Pentium 4 5XX and Celeron D 3xx sequence processor.
Support Intel 04B and 04A processors.
Supports Intel Hyper-Threading technology.
Supports up to 3.8GHz, FSB@800/533MHz
Chipset
VIA® P4M800 Chipset
64-bit P4 processor FSB 800MHz
64-bit DDR SDRAM memory DDR 333/400MHz
32-bit AGP (66MHz) for 8x/4x mode
Supports 8X V-Link
VIA® VT8237R Chipset
Integrated Direct Sound AC'97 audio.
Dual channel Ultra DMA 33/66/100/133 master mode EIDE controller.
Integrated USB 2.0 controller.
ACPI & PC2001 compliant enhanced power management
Main Memory
Supports four memory banks using two 184-pin DDR DIMM.
Supports up to 2GB DDR333/400 SDRAM.
Supports 2.5v DDR SDRAM.
Slots
One AGP (Accelerated Graphics Port) 8x/4X slot.
Two PCI 2.2 32-bit PCI bus slots (support 3.3V/5V PCI bus interface).
On-Board IDE
An IDE controller on the VT8237R chipset provides IDE HDD/ CD-ROM with PIO, Bus Master and Ultra DMA133/100/66 operation modes.
Can connect up to four IDE devices.
Video
S3 UniChrome Pro integrated graphics
Audio
AC'97 link controller integrated in VIA® VT8237R
Realtek ALC655 2/6 channel S/W audio codec.
Compliance with AC'97 v2.2 spec.
Meets PC2001 audio performance requirement.
LAN
Realtek 8201CL
Integrated Fast Ethernet PHY.
Supports 10Mb/s and 100Mb/s auto-negotation operation.
Compliance with PCI v2.2 and PC99 standard.
Supports ACPI power management.
Internal I/O Connectors
ATX 20-Pin power connector
4-pin ATX 12V power connector
CPU / System / Power connectors
CD-in connector
Clear CMOS jumper
SPDIF-out connector
Serial port connector (COM2)
2 x USB 2.0 connector support additional 4 ports
Front panel audio connector
Front panel connector
1 x Floppy disk drive connector
2 x Ultra DMA 133 IDE device connectors
2 x Serial ATA device connectors
Back Panel I/O Ports
1 x Parallel
1 x Serial port (COM 1)
1 x VGA
1 x PS/2 Keyboard
1 x PS/2 Mouse
1 x Audio I/O (Line-in/Line-out/MIC)
4 x USB 2.0
1 x RJ45 LAN Jack
