Mounting
Maximum screen size compatibility |
65 " |
Minimum screen size compatibility |
40 " |
Minimum VESA mount |
100 x 100 mm |
Maximum VESA mount |
600 x 400 mm |
Number of displays supported |
2 |
Maximum weight capacity |
30 kg |
Suitable for |
Public display |
Technical details
Cord management |
Y |
Ceiling mounting tube length (min) |
580 cm |
Ceiling mounting tube length (max) |
1550 cm |
Mounting type |
Ceiling |
Certification |
CE |
Adjustable |
Y |
Ergonomics
Height adjustment |
Y |
Pivot angle |
-4 - 4 ° |
Swivel angle |
360 ° |
Tilt angle |
0 - 15 ° |
Weight & dimensions
Depth |
200 mm |
Weight |
25000 g |
Width |
2220 mm |
Height |
3380 mm |
40 - 60", Max 30 kg, VESA 600 x 400 max, Adjustable, 25 kg, Black
M Menu Board Mount Pro MBC2X1U
M Menuboard Mount Pro MBC2X1U - Ceiling mount for LCD display, steel, 3m length, 2 screens, single side, tilt arms, VESA Max 600x400 - screen size: 40"-65" - black
The M Menuboard Mount Pro MBC2X1U is our 2 screen side by side menuboard system - ready to be installed.
The professional Pro Series A/V line from Multibrackets was designed with the installer in mind. Modular, easy to configure, quick to install and simple to maintain. Developed together with installers we added close to unlimited flexibility and versatility. Based on the Pro Series ultra-flexible aluminum rail it is completely modular and has built in cable management throughout the entire solution to quicken installation and create an esthetic result worth the public eye.
With its modular construction installers can tailor the MBC2X1U with the clients need in mind. Possibilities to change, update and reconfigure its design and if ideas change over time Pro Series can follow.
The M Menuboard Mount Pro MBC2X1U creates a seamless mounting surface through the aluminum rail. The tilted mounting of the displays allow all displays to be placed side by side and tilted at the same angle with ease creating alignment and true menuboard perfection.
Designed with our Scandinavian heritage in mind Pro Series provides a clean Nordic look where each part and detail is made as simple as can be and still service its function. Possible to use in a variety of environments our Pro Series Menuboards are truly versatile. The Pro Series possibilities to extend pipes and add details by individual choice is vast so that one can tailor each mount to its location and function. With included hardware kit a basic installation should not be a hassle.
Multibrackets Pro Series Menuboards is simply ideal for any large screen digital signage application.
Highlights
- A professional, flexible and modular product
- Includes VESA adapters for compatibility up to VESA 600x400
- Integrated cable management throughout the entire solution
- Power click install for an easy, fast and safe installation
- Ceiling plate included
- Portrait or landscape position of screen possible
- Hardware kit included
