Product types: AV receiver, network receiver
Speaker configuration: 11.2
Technical specifications
Construction: with remote control
HDMI functions: HDMI-CEC, HDMI zone switching
HDMI version: HDMI 2.0
Connections
analog audio inputs: 5x LINE In (Cinch/RCA, Stereo), 1x MM Phono In (Cinch/RCA, Stereo)
analog audio outputs: Zone 2 (Line Out, Cinch/RCA, Stereo), Zone 3 (Line Out, Cinch/RCA, Stereo), 2x Line Out (Cinch/RCA, Stereo)
digital audio inputs: 2x S/PDIF IN (Cinch/RCA coaxial), 3x S/PDIF IN (TOS-Link optical)
HDMI ports: 2x HDMI-Out, 8x HDMI-In
Video connections: 1x Component OUT, 1x Composite OUT, 2x Component IN, 2x Composite IN
Preamp outputs: 11.2 Surround (Cinch/RCA), 2x Subwoofer (Cinch/RCA)
Front Connections: 1x USB 2.0 Type-A, headphone output, 1x measurement microphone (Setup Mic)
Data connections: Network connection, USB
Connections for control signals: RS-232, 1x 12V Trigger OUT, 1x Remote IN
additional connection: Antenna connection
gold-plated connections: no
Audio
Audio functions: High-Resolution Audio, VLSC Signal Processing, LipSync
Dolby Format: Dolby Atmos
DTS Formats: DTS:X, DTS Neural:X
THX Formats: THX Select 2 Plus
Number of listening zones: 3
Video
Supported Resolutions: Full HD
Video functions: 4K Pass-Through, HDCP 2.2
Connectivity
Network functions: HDMI Ethernet Channel (HEC)
Wireless transmissions: AirPlay, Fire Connect, Chromecast, Bluetooth, WLAN
Streaming services: Deezer, TuneIn, Spotify, Tidal
Functions
Comfort features: Graphical User Interface (GUI), On-Screen Display (OSD)
automatic measurement: yes
Calibration system: AccuEQ
Power supply
Power consumption in operation: 65 Watt
Power consumption standby: 0,2 Watt
additional features
Weight: 13,6 kg
Housing property: Metal
Further properties
Remark: No power amplifiers / Output via 11.2 XLR connectors
