WV-ASM100, i-Pro Management Software
Highly scalable Management Software for the i-Pro Network Surveillance System.
WV-ASM100 enables large scale multi-site surveillance system with management efficiency and user-friendly operation. Up to 100 recorders, 64 encoders and 256 directly connected cameras can be registered, enabling images from up to 6912 cameras to be viewed at the monitoring site. The WV-ASM100 Version 6 supports H.264, MPEG-4 and JPEG images from i-Pro series cameras, encoders and recorders, and up to 20x 30 ips/camera images can be displayed. The WV-ASM100 Version 6 also supports WJ-HD616/716 Digital Video Recorders so that analog cameras can be integrated with the i-Pro Network Surveillance System. The line up includes WVASM100L light version and WV-ASM10 monitoring software.
Extensive Management Capability
Up to 100 recorders, 64 encoders and 256 directly connected cameras can be registered. Up to 6,400 cameras registered in the recorders and 256 cameras registered in the encoders are automatically registered in the WV-ASM100.
H.264, MPEG-4, JPEG
H.264, MPEG-4, JPEG from the i-Pro series and WJ-HD616/716 (H.264 only) are supported.
User Friendly GUI with Multi-Monitor Operation
User friendly GUI with illustrated camera, alarm and recorder icons allows intuitive operations including display mode, camera control, recorder control and status monitoring. Multi-Monitor option enables simultaneous use of operation display (1 / 4 / 9 / 16 split), Live display (1 / 4 / 9 / 16 split) and Map display each on a dedicated monitor. Single or two monitor operation is also available. Up to 20 cameras (16+4 or 4+16) can be displayed with the operation monitor and the live monitor at a time.
High Frame Rate
Up to 20x 30 ips/camera images can be displayed in H.264 1.5 Mbps mode (VGA: Normal quality mode). Up to 20x 30 ips/camera images can be displayed in MPEG-4 2 Mbps mode (VGA: Normal quality mode).
Operation Display
User friendly GUI with illustrated camera, alarm and recorder icons allows intuitive operations including display mode, camera control, recorder control and status monitoring.
Map Display
Up to 64 camera icons and 20 map link incons can freely be positioned on a map. Up to 100 maps can be selected by the pull down menu or by the map icons. When a camera generated an alarm, the map with colored camera icon in which the alarm camera is located is displayed on front. *1
Camera Group Display
Up to 400 camera groups: Up to 16 cameras can be assigned in a multiscreen (1/4/9/16) as a group and called up on the operation display or the live display by manual or sequence operation. Recorder or encoder can also be assigned in a group in that cameras are automatically assigned from camera 1 in order.
Camera Control
Panasonic camera control: Pan/Tilt, Zoom, Focus, Brightness, Preset position call and program (up to 256), Auto mode, AUX 1 ~ 3, Click Centering, Wheel Zoom (depending on the camera model).
Recorder Control
Recorder control such as playback, search, record download can be made by using the operation display. 7 speeds (up to 96x ) are available for forward/reverse playback. To playback the recorded images, display live image of the desired cameras. Click HDD tab to display the recorder operation panel, then click PLAY.
Operation with WV-CU950
A camera, a group or a sequence can be called up on the operation display by their ID with the optional system controller WV-CU950.*1 The camera displayed in the active window can be controlled by the system controller. Playback operation can also be made by the system controller with Jog/Shuttle.
Dynamic Resolution Adjustment: JPEG
Image resolution can automatically be adjusted depending on the screen mode (VGA: 1/4 screen, QVGA: 9/16 split screen), enabling optimum network usage. Fix mode is also available. (JPEG, Camera direct mode)
Dynamic Stream Switching: H.264/MPEG-4
Two video streams from a camera can automatically be selected depending on the screen mode (1/4 screen: Stream1, 9/16 screen: Stream2), enabling megapixel resolution for Spot/Quad display. Fix mode is also available. (H.264/MPEG-4, Camera direct mode)
Flexible Alarm Handling
Versatile alarm actions: A pop-up alarm message on the operation display, The map with colored camera icon in which the alarm camera is located is displayed on front, Up to 16 split live images on the live display and buzzer. Live or playback images can be viewed by clicking the icon in the alarm message.
REC Event Search
Desired record can be searched by various criteria such as Camera number, Time & Date, Event Type including i-VMD and Text on/off.
Cameras can be selected from the recorders, camera groups or the maps Record in the multiple recorders can be searched simultaneously.
Playback VMD Search
Recorder’s Playback VMD Search function can be operated from the operation display. 4 areas, 3 sensitivities, camera number start/end time, and mask duration can be specified.
User Management
Sophisticated user management: User authentication with time limited password, 5 user levels, User-Camera View/Control partitioning in conjunction with recorder’s user management function, Up to 32 user registrations
Video Analytic
Detection frames and motion trails of the moving subjects can be displayed when used with the WJ-NT314.
Bi-directional Audio
Audio from a camera can be heard and the operator voice can be transmitted to the camera’s audio output through the network (single channel at a time).
Multi-site System
WV-ASM100 enables large scale multi-site surveillance system with management efficiency and user-friendly operation.
