Performance
| Motherboard form factor |
Micro ATX |
| Audio system |
C-Media CMI9738 |
BIOS
| BIOS memory size |
2 MB |
| ACPI version |
1.0 |
Back panel I/O ports
| Parallel ports quantity |
1 |
| Serial ports quantity |
1 |
| PS/2 ports quantity |
2 |
| Headphone outputs |
1 |
| Microphone in |
Y |
| VGA (D-Sub) ports quantity |
1 |
Other features
| Graphics controller |
Real256 3D |
Internal I/O
| USB 2.0 connectors |
1 |
| Number of Parallel ATA connectors |
2 |
| Floppy disk drive connector |
Y |
| CD/AUX audio in |
Y |
| CPU fan connector |
Y |
| GAME/MIDI connector |
Y |
| Chassis intrusion connector |
Y |
| Number of EATX power connectors |
1 |
| Front panel audio connector |
Y |
| Audio Modem Rise (AMR) slot |
Y |
Graphics
| Maximum graphics adapter memory |
64 MB |
| On-board graphics adapter |
Y |
Memory
| Number of memory slots |
4 |
| Maximum internal memory |
2 GB |
Networking
| Networking features |
Fast Ethernet |
Packaging content
| Quick installation guide |
Y |
Additionally
| Ethernet LAN (RJ-45) ports quantity |
1 |
M810DG (V8.0a), socket A, SiS 740/962L, Micro-ATX, DDR, PCI, 2x184-pin/2x168-pin DIMM, 2xUltraDMA, Fast Ethernet
M810DG (V8.0a)
M810DG V8.0A is the most advance and unique module from PCCHIPS production. It supports Socket A for Athlon XP CPU, 266MHz FSB, 2 unbuffered DDR266 DDRAM and 2 unbuffered PC133 SDRAM memory to deliver the best flexibility, price and performance.
10/100 LAN
Provides 10/100 Mbps solution to your network or broadband connection without having to buy an extra LAN card.
USB 2.0
USB 2.0 is the latest connectivity standard which delivers transfer speeds up to 480Mb/s for easy connectivity and ultra-fast data transfers.
Color Map
Color-coded pin headers and slots make it easy to match plug that plugs with cables without checking the silk screen for installation instructions.
ATA133
Supports Ultra DMA 33/66/100/133 IDE devices, data transfer rate up to 133MB/s.
