Product types: Network receiver, AV receiver
Speaker configuration: 11.4
Power per channel: 150 Watt
Technical specifications
Output power: 9 x 180 Watt
Output impedance: 6 Ohm
Speaker connection: Screw terminals
max. sample rate: 384 kHz
Bitrate: 32 Bit
Constructions: Digital Signal Processor (DSP), Digital Amplifiers
HDMI functions: HDMI-eARC, HDMI Standby Through, HDMI Standby Input Switching
Connections
analog audio inputs: 4x LINE In (Cinch/RCA, Stereo), 1x MM Phono In (Cinch/RCA, Stereo), 1x LINE In (balanced, XLR Stereo Pair)
analog audio outputs: Zone 2 (LINE Out, Cinch/RCA, Stereo), Zone 3 (LINE Out, Cinch/RCA, Stereo), 1x LINE Out (balanced, XLR stereo pair)
digital audio inputs: 2x S/PDIF IN (Cinch/RCA coaxial), 3x S/PDIF IN (TOS-Link optical)
HDMI ports: 7x HDMI In, 3x HDMI Out
Video connections: 1x Component IN, 2x Composite IN
Preamp outputs: 11.4 Surround (Cinch/RCA), 7.2.4 Surround (Cinch/RCA)
Front Connections: HDMI Input, 1x USB 2.0 Type-A, Headphone Output, 1x Measurement Microphone (Setup Mic)
Data connections: Network connection, USB
Connections for control signals: RS-232, 1x Remote IN, 1x Remote OUT, 2x 12V Trigger OUT
additional connection: Antenna connection
gold-plated connections: no
Audio
Audio functions: DSD Audio compatible, IMAX Enhanced
Dolby formats: Dolby Atmos, Dolby Surround
DTS Formats: DTS:X, DTS Neural:X
Auro 3D: yes
Number of listening zones: 3
Video
Supported Resolutions: UHD, Full HD, 8K
Video functions: Deep Color, x.v.Color, 4K Pass-Through, HDR10, HLG (Hybrid Log Gamma), Dolby Vision, BT.2020 Support, High Dynamic Range (HDR), HDCP 2.3
3D-Ready: yes
Connectivity
Network functions: Control via app, audio streaming, network streaming
Wireless transmissions: Fire Connect, AirPlay 2, AirPlay, Chromecast, DTS Play-Fi, Bluetooth, WLAN
Streaming services: Deezer, TuneIn, Spotify, Tidal, Amazon Music, Internet radio, Pandora
Functions
Comfort features: Graphical User Interface (GUI)
Environmental properties: Sleep Timer, Auto Power Off, Standby Passthrough
automatic measurement: yes
Calibration systems: Dirac Live, MCACC Pro
Reception areas: FM (UKW), AM (MW), DAB
Number of station presets: 40
Smart Home
Voice assistant: Google Assistant
additional features
Dimensions: 435 x 185 x 386 mm
Weight: 13 kg
Housing property: Metal
Color: black
