Ports & interfaces
| RJ-45 output ports |
8 |
| VGA (D-Sub) input ports |
1 |
| DC-in jack |
Y |
| VGA (D-Sub) output ports |
1 |
Technical details
| Audio system |
stereo |
| Type |
AV transmitter |
| Cable types supported |
Cat5e, Cat6 |
| Maximum transfer distance |
300 m |
Power
| Operating voltage |
12 V |
| External power adapter |
Y |
QVS 8Port VGA/QXGA @ Stereo Audio CAT5/RJ45 Extender System Transmitter Module @ Local Port, 2048x1536 @ 60Hz - 50m, 1280x1024 @ 60Hz - 100m, 1024x768 @ 60Hz - 180m, 800x600 @ 60Hz - 200m, 640x480 @ 60Hz - 300m
Extends video signal up to 300 meters (984ft) using the VGA Extender System and CAT5/RJ45 cable. This transmitter or local module provides 8 VGA/Audio distribution amplifier port over CAT5 plus local port that allows connection of another monitor near the computer. Supports 96KHz audio sampling rate and maximum video resolution of 2048x1536 @ 60Hz for up to 50meters, 1280x1024 @ 60Hz for up to 100meters, 1024x768 @ 60Hz for up to 180meters, 800x600 @ 60Hz for up to 200meters, & 640x480 @ 60Hz for up to 300meters. This must be used in conjunction with VAC5-ER or VAC5-ERP Extender System's Receiver/Remote Module. Includes transmitter and power adaptor. Required Cables: Solid CAT5e/6 Cables. (Connectors: 3.5mm/HD15/RJ45 Females).
