Performance
Analog signal format system |
PAL, PAL 60, SECAM |
Multi-display supported |
Y |
TV tuner integrated |
Y |
HDCP |
Y |
Ports & interfaces
Component video (YPbPr/YCbCr) out |
1 |
PC Audio in |
Y |
DVI port |
Y |
S-Video in |
Y |
USB port |
N |
HDMI ports quantity |
1 |
Component video (YPbPr/YCbCr) in |
1 |
VGA (D-Sub) input ports |
1 |
Composite video in |
1 |
DVI-D ports quantity |
1 |
Other features
Headphone connectivity |
3.5 mm |
DC-in jack |
Y |
Design
Bezel width (top) |
2.4 mm |
Bezel width (bottom) |
4.1 mm |
Additionally
Ethernet LAN connection |
Y |
TFT, 60'', 366 X 768, 700 CD/M2, 2400:1, 6
60" Class (60" Diagonal) Screen Size
- with Sharp UV2A LCD Technology provides exceptionally deep blacks and bright vivid colors with up to 700 cd/m2 brightness and 4000:1 contrast ratio.
World’s Slimmest Bezel
- (Based on available information, as of June 8, 2010, for LCD panels of 46-inches or larger in size.) Thanks to its ultra-slim bezel, multiple PN-V601A monitors can be joined together to create high impact multi-screen displays. The width of the bezel between neighboring monitors in a multi-screen display is only 6.5 mm (2.4mm on the right and bottom, and 4.1 mm on the left and top). (Total non-display area for neighboring monitors is 7.1 mm.)
Full Array LED Backlight
- gives the PN-V601A more uniform brightness than conventional CCFL backlighting. LED elements are positioned across the entire panel directly behind the liquid crystal layers, helping ensure beautiful uniform images.
1366 x 768 Resolution - from analog RGB, digital RGB and HDTV video sources. When used in a 3x3 video wall display, this Professional LCD Monitor provides over 4K x 2K total resolution (4098 x 2304 pixels) for ultra-high resolution / ultra-high impact images.
Enlarge (Zoom) Display Mode
- enables one image to be spread across up to 25 monitors (in up to a 5x5 configuration). The Frame Width Adjustment function eliminates misalignment and helps enhance the enlarged image in a multi-screen display.
24/7 Certified
- for use in most commercial applications.
3-Year On-Site Limited Warranty
- covers parts, labor and backlight in both landscape and portrait modes.
Built-in 10 Watt per Channel Amplifier
- for use with external stereo speakers.
Extensive Interface Capability
- Standard interfaces include HDMI® input, D-Sub 15-pin RGB input, stereo audio input, stereo audio line-output and RS-232C input/output.
Optional Input/Output Expansion Board (PN-ZB02)
- adds DVI-D input/output, 5-BNC analog RGB input, component video input, S-video input, composite video input (BNC), stereo audio (RCA) input x 2, RJ-45 LAN display control and stereo speaker output (10W x 2).
Optional Mounting Hardware Bundles
– includes all of the hardware needed for the most popular video wall configurations, for both wall mounting and free standing installations.
Compatible with SDSS Sharp Digital Signage Software
ENERGY STAR® Qualified
- with exceptionally low power consumption.
