Performance
| Analog signal format system |
NTSC |
| TV tuner integrated |
N |
| HDCP |
Y |
| Operating hours (hours/days) |
24/7 |
Ports & interfaces
| PC Audio in |
Y |
| DVI port |
Y |
| Ethernet LAN data rates |
10, 100 Mbit/s |
| RS-232C |
Y |
| HDMI ports quantity |
1 |
| VGA (D-Sub) input ports |
1 |
| DVI-D ports quantity |
2 |
| USB ports quantity |
1 |
Design
| Bezel width (top) |
9.5 mm |
| Bezel width (bottom) |
15.6 mm |
Display
| Active display area (W x H) |
941.2 x 529.4 mm |
| HD type |
Full HD |
| Display type |
LED |
Technical details
| RS-232 input ports |
1 |
| RS-232 output ports |
1 |
| DVI input ports |
1 |
| DVI output ports |
1 |
| LED backlighting type |
Edge-Lit LED |
Other features
| Compatible memory cards |
SD |
| Card reader integrated |
Y |
Packaging data
| Handheld remote control |
Y |
| Batteries included |
Y |
Additionally
| Ethernet LAN (RJ-45) ports quantity |
1 |
| Ethernet LAN connection |
Y |
109.22 cm (43 ") , TFT LCD, 1920 x 1080, 450 cd/m², 1100 : 1, 12 ms, 2x DVI-D, Mini D-sub, HDMI, 2x RS-232C, 3x 3.5mm, USB, SD, RJ-45, 14 W RMS, 100-240 V, 50/60 Hz, 965 x 46 x 559 mm
Sharp offers an effective and convenient solution for digital signage. Our PN-Y556/Y496/Y436/Y326 LCD monitors are designed for ease of use and flexibility in a variety of settings. Simple and stylish, they have the functionality to support easy content distribution. Whether in a retail, public, or office setting, these monitors can help convey your message and make an eye-catching impression. So if you're seeking a multifaceted signage solution with round-the-clock reliability and easy content distribution, these affordable slimline monitors offer outstanding value.
The Quality to Present Attractive Signage
Excellent Image Quality
Full HD (1,920 × 1,080) resolution brings images to life with vivid, true-to-life details. Everything from thin lines to fine text to photographic images can be displayed in stunning clarity.
Simple and Stylish Design
A narrow 9.5-mm bezel keeps the emphasis on onscreen content, so that information is conveyed clearly and attractively. The simple and stylish design matches a variety of locations and business settings, from small shops to large corporations and industrial environments.
Adaptable to Various Settings
Whether in a landscape or portrait orientation, these monitors can be installed face up, face down, or tilted forward or backward at an angle of up to 90 degrees. Such flexibility helps you to incorporate the monitors into a wider-than-ever variety of settings.
Easy and Versatile Signage Support
PN-Y556/Y496/Y436/Y326 LCD monitors support easy daily usage and versatile content distribution. Simply insert a USB memory device or SD card for plug-and-play operation. Using a specified wireless SD card equipped with an original Sharp HTML application, you can distribute content wirelessly from a PC or mobile device. Furthermore, SHARP Content Distributor software supports convenient content distribution and management via network. Thanks to their versatile signage capabilities, these monitors make it easy to convey messages in public spaces or commercial locations, or promote internal communication in the office.
Autoplay via Media Player
Displaying still images or videos couldn’t be easier. Just insert a USB memory device or SD card into the LCD monitor and the built-in media player starts playing your content right away. There’s no need for a PC and cables. It’s easy for anyone to operate.
Easy Overwrite via Wireless LAN
With a specified wireless SD card, you can wirelessly overwrite the content stored on the card. Using a wireless LAN makes it easy to distribute content from a PC, tablet or other mobile device, giving you a convenient data-transmission experience. There’s no need to insert or remove the card at the back of the monitor when you want to overwrite the content. This not only saves you time, it also gives you more freedom to install the monitor where it’s hard to reach—for example in a high place.
Timely Content Distribution via Network
Operating over a LAN, SHARP Content Distributor software makes it easy to update the content to be displayed on multiple LCD monitors. Through simple and intuitive PC operation, you can schedule what content gets distributed, when it gets delivered, and which monitors show it. Take advantage of a convenient signage solution that lets you distribute content in a timely manner to multiple PN-Y556/Y496/Y436/Y326 monitors.
Content List
Register up to 50 content lists, each comprising up to 30 files of either pictures or videos. Creating and updating a customised content list is simple, thanks to intuitive operation.
Scheduling
Set a time and day of the week for content distribution to a maximum of 20 pre-registered LCD monitors. Up to 7 schedule patterns can be registered.
Intuitive drag-and-drop operation with thumbnail viewEasy editing of distribution schedules
Log Management
Easily manage individual content distribution logs that include date/time, results, and names of content lists, as well as IP addresses, names, and locations of monitors. This information can be viewed and managed on a PC screen.
