Display
Sync-on-green (SOG) |
Y |
Separate H/V sync |
Y |
Viewable size, horizontal |
1039.81 mm |
Viewable size, vertical |
584.2 mm |
HD type |
Full HD |
Native aspect ratio |
16:9 |
Composite sync |
Y |
HDCP |
Y |
Multimedia
Analog signal format system |
NTSC, PAL, PAL 60, SECAM |
Swivel webcam |
N |
Number of speakers |
2 |
TV tuner integrated |
N |
Built-in camera |
N |
Ports & interfaces
Composite video in |
1 |
PC Audio in |
Y |
DVI-D ports quantity |
1 |
Headphone connectivity |
3.5 mm |
Headphone outputs |
1 |
Component video (YPbPr/YCbCr) in |
1 |
HDMI ports quantity |
1 |
VGA (D-Sub) ports quantity |
1 |
Weight & dimensions
Bezel width (top) |
19.5 mm |
Bezel width (bottom) |
19.5 mm |
Packaging content
Handheld remote control |
Y |
Ergonomics
On Screen Display (OSD) |
Y |
Additionally
S-Video in |
1 |
RS-232 port |
2 |
Ethernet LAN connection |
Y |
Ethernet LAN (RJ-45) ports quantity |
1 |
119.38 cm (47 ") , 1920 x 1080, 700 cd/m2, 16:9, 9 ms, CR 1200:1, 1 x HDMI, Composite, YCb/PbCr/Pr, DVI-D 24-pin, RS-232C, RJ-45, D-sub 15-pin, S-Video, 3.5 mm Mini Stereo, RMS 20W
The 47" Class (46-15/16" Diagonal) PN-E471R LCD monitor offers exceptionally high image quality and reliability for use in commercial display and digital signage applications. 24/7 certified, the thin bezel PN-E471R offers full 1920 x 1080 (1080p) resolution from analog RGB, digital RGB and HDTV video sources along with compatibility for use in both portrait and landscape modes. Fanless architecture helps ensure ultra-quiet reliable operation, and optional input/output expansion board and signage controller provide maximum flexibility. The PN-E471R LCD display professional monitor is fully compatible with SDSS Sharp Digital Signage Software and is backed by a 3-year on-site limited warranty (covering parts, labor and backlight). Also available is the PN-E471RP, which features an integrated protective overlay for use in high traffic areas.
Features
- 47" Class (46-5/16" Diagonal) Screen Size - with 700 cd/m2 brightness and 1200:1 contrast ratio.
- Full 1920 x 1080 (1080p) Resolution - from analog RGB, digital RGB and HDTV video sources.
- 24/7 Certified - for use in most any commercial application.
- 3-Year On-Site Limited Warranty - covers parts, labor and backlight in both landscape and portrait modes.
- Advanced Fanless Architecture - operates silently with maximum reliability.
- Thin Bezel Design along with Enlarge (Zoom) Display Mode - enables easy installation of high-impact video walls of up to 5 x 5. (Some installations may require additional third-party hardware.)
- Built-in 10 Watt per Channel Stereo Speakers - eliminates need for an external audio system for many installations.
- Extensive Interface Capability - Standard interfaces include HDMI input D-Sub 15-pin RGB input, stereo audio input, stereo audio line-output and RS-232C input/output.
- Optional Input/Output Expansion Board (PN-ZB01) - adds DVI-D input/output, 5-BNC analog RGB input, component video input, S-video input, composite video input (BNC), stereo audio (RCA) input x 2, RJ-45 LAN display control and stereo speaker output (10W x 2).
- Optional Signage Controller (PC) - easily attaches to rear of display. Permits all-in-one digital signage display package.
- Compatible with SDSS Sharp Digital Signage Software
- Available with Integrated Protective Overlay (PN-E471RP) - to enable use in high traffic applications.
- ENERGY STAR Qualified - with exceptionally low power consumption.
