Processor special features
| Intel 64 |
Y |
| Execute Disable Bit |
Y |
| Thermal Monitoring Technologies |
N |
| Intel Trusted Execution Technology |
N |
| Number of Processing Die Transistors |
176 M |
| Embedded options available |
Y |
| Intel Virtualization Technology for Directed I/O (VT-d) |
N |
| Intel Hyper-Threading Technology |
Y |
| Intel® Turbo Boost Technology |
N |
| Intel Enhanced Halt State |
N |
| Enhanced Intel SpeedStep Technology |
N |
| Intel Demand Based Switching |
N |
Other features
| Redundant fans description |
1 x 90 mm, 12V DC |
| Manageability features |
Single Disk, JBOD,Online RAID, HDD S.M.A.R.T., AES 256-bit |
Performance
| Linux operating systems supported |
Y |
| Device class |
Home & Home Office |
| Mac operating systems supported |
Mac OS X 10.0 Cheetah, Mac OS X 10.1 Puma, Mac OS X 10.10 Yosemite, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks |
| Type |
NAS |
| Number of users |
4096 user(s) |
Storage
| Number of storage drives supported |
4 |
| Number of storage drives installed |
4 |
| Supported storage drive types |
HDD |
| Installed storage drive type |
HDD |
| Storage drives installed |
Y |
| RAID support |
Y |
| Total installed storage capacity |
4000 GB |
| Hot-swap drive bays |
Y |
| Storage drive capacity |
1000 GB |
Processor
| Processor cache |
1 MB |
| Processor lithography |
45 nm |
| Thermal Design Power (TDP) |
13 W |
| Physical Address Extension (PAE) |
32 bit |
| Processor package size |
22 mm |
| Processor ARK ID |
43098 |
| Processor code |
SLBLA |
| Processor codename |
Pineview |
| Processor cache type |
L2 |
| Memory bandwidth supported by processor (max) |
6.4 GB/s |
| Conflict Free processor |
N |
| Tjunction |
100 °C |
| Processor operating modes |
64-bit |
| L2 cache |
1 MB |
| Stepping |
B0 |
| Processor cores |
2 |
| Processor frequency |
1.66 GHz |
| Maximum internal memory supported by processor |
4 GB |
| ECC supported by processor |
N |
| Bus type |
DMI |
Networking
| iSCSI support |
Y |
| DHCP client |
Y |
| DHCP server |
Y |
| Wi-Fi |
N |
| Supported network protocols |
CIFS/SMB, AFP, NFS HTTP, HTTPS, FTP, DDNS, NTP |
Power
| Power supply unit (PSU) capacity |
250 W |
Ports & interfaces
| eSATA ports quantity |
2 |
| eSATA |
Y |
Additionally
| Internal RAM type |
DDR2 |
| Processing die size |
87 mm² |
| Internal RAM |
1 GB |
| Jumbo Frames support |
Y |
| Ethernet LAN connection |
Y |
| Intel AES New Instructions |
N |
| Ethernet LAN (RJ-45) ports quantity |
2 |
Intel Atom D510 (1M Cache, 1.66 GHz), 4TB, 1GB DDR2, 250W, Linux
The Tandberg Data DPS2040™ is a flexible, high performance, affordable disk system that provides simple file sharing, consolidated iSCSI storage, and data protection for SMBs in a compact desktop unit. The DPS2040 installs quickly and provides cross-platform network storage for safe, effective storing, sharing, and protecting of business-critical data for small to medium businesses, departments, and distributed enterprises.
Flexible Storage Management
The Tandberg Data DPS2040™ provides users with the ability to extend storage and share data on a single cost-effective platform. Because of its versatility, the DPS2040 can be configured as a file server or an iSCSI target server, providing simultaneous file-level access and block-level storage for maximum disk utilization. File-level volumes can be used for file sharing, D2D backup, and IP video capture.
Sharing your files has never been easier because the DPS2040 provides the ideal platform for simple consolidated business-grade file sharing across Windows, Macintosh, or Unix/Linux systems. Manage user quotas, accounts, and groups via the integrated web console or through simple active directory integration for maximum security.
The DPS2040 provides a simple and flexible way to add storage to a server. Each DPS2040 can create up to 8 unique iSCSI targets allowing users to extend local server storage without system disruption.
Business-Use Design
The advanced RAID configuration of the DPS2040 allows users to increase capacity through physical HDD migration. During the HDD swap, all data residing on the legacy hard drive is seamlessly migrated to the newly installed drive without server downtime. In addition, the virtual appliance stacking feature enables multiple DPS2040 units to be stacked for increased volume.
Powerful Data Protection
Tandberg Data AccuGuard data protection software delivers reliable, automated backup, and recovery. Using its powerful data deduplication engine increases your effective storage capacity, allowing you to store 20 times more data. AccuGuard intelligently optimizes the data at the source resulting in drastically improved backup windows and network bandwidth. Data retrieval is simple and painless with AccuGuard’s flexible file searching, drag-and-drop restore, and point-in-time disaster recovery. With integrated Microsoft Exchange and SQL support, server protection has never been easier.
Service and Support
The DPS2040 comes with 1 year On-site Service (5x9xNBD on-site service is available in many regions around the world. Contact Tandberg Data for availability in your region.) and warranty. Additional service options are available.
TheDPS2040 provides simple, robust storage for small to medium business environments, distributed enterprises, and remote offices.
