Performance
| 2.4 GHz |
Y |
| Number of users |
5 user(s) |
| 5 GHz |
N |
| Operating modes |
Access Point; Universal Repeater; Station(Client) ; WISP (Client+Router); Client+AP |
| Transmitting power |
20 dBmW |
| Ethernet LAN data rates |
10, 100 Mbit/s |
| Maximum indoor range |
40 m |
| Reset button |
Y |
| Frequency band |
2.4 - 2.483 GHz |
Protocols
| Supported network protocols |
http/https |
| DHCP server |
Y |
| DHCP client |
Y |
Security
| Number of SSID support |
8 |
| SSID Broadcast on/off |
Y |
Power
| Power over Ethernet (PoE) |
Y |
Antenna
| Antenna gain level (max) |
5 dBi |
Additionally
| AC adapter bundled |
Y |
| Ethernet LAN (RJ-45) ports quantity |
1 |
| Transfer rate (Mbps) |
300 Mbit/s |
IEEE 802.11n/g/b, 40m, 2.4 - 2.483GHz, 300/54/11 Mbps, DC 9V, 0.6A, 4W, 20dbm
<b>What It Does</b>
AP4 is designed to boost the range of your existing WiFi and creates a stronger signals in a hard to reach areas for game consoles, printers, smart phone, tablet. Power over ethernet supported and wall-mount design make it flexible to deploy in any location. The AP features with multi operation modes like Universal Repeater, Client(Station), WISP to adapt various application scenarios. It is a ideal Wi-Fi booster for large houses, villas,eatery, large stores etc.
- One Button to boost Wi-Fi coverage of ADSL modem or router.
- 300Mbps wireless transmission rate brings smooth wireless experience.
- Multiple operating modes include AP/Univesal Repeater/WISP/Client/Client+AP.
- Power over Ethernet with included Injector make it flexible to deploy.
<b>Button to boost Wi-Fi Range</b>
AP4 features Range Extender Button that allows users to boost existing Wi-Fi Range simply by pressing the "Range Extender" button.
<b>Flexible deployment</b>
Wall-Mount design and power over ethernet cable supported make it flexible to deploy in place without power outlet such as garage,warehouse etc.
<b>Operating Modes for Various Scenarios</b>
Multi operating modes including AP,Universal Repeater,WISP(Client+Router), Station(client) help you to boost WiFi range in various scenarios such as large house,villa, eatery,stores, community network.
<b>Easy to Manage With AP Controller</b>
AP4 can be managed by the AP controller AC500 from Tenda. When you deploy multi APs in networks, you can configure SSID(Wireless network name), Channel, Security Key, Output power etc option through AC500 in a single location.
