Product types: Shelf speaker, WIFI speaker, Bluetooth speaker
Series: Teufel Definition
Operation
Principle: active
Power supply: Network operation
Equipment
Playback formats: AAC, ALAC, ASF, FLAC, MP3, WAV, WMA
Reception area: Web radio
Functions: Internet radio, streaming, station memory, sleep timer
available music services: Amazon Music, Apple Music, Spotify
Control via: Buttons, App
Smartphone control app: Raumfeld App
Features: Precision Channel, Synchronized Coaxial Acoustics
Control properties: Forward/Backward, Play/Pause, On/Off, Volume, Bluetooth Pairing
Performance
Speaker System: 2.0 Stereo
recommended amplifier power: 25 Watt
Amplifier types: digital, Class D
Nominal load: 100 Watt
System: 3-way
Transition frequencies: 450 Hz, 3,300 Hz
Frequency response: 50 - 22.000 Hz
Frequency response of: 50 Hz
Frequency response up to: 20.000 Hz
Volume: 14,5 Liter
Impedances: 4 Ohm, 6 Ohm, 8 Ohm
Sound pressure level: 102 dB
Connections
digital input: USB
analog inputs: Audio (RCA), Line-In (3.5mm Jack)
additional connection: Network connection LAN (RJ-45)
Bluetooth version: Bluetooth 4.2
Bluetooth Codec: SBC
Bluetooth profile: A2DP
Wireless transmissions: WLAN, Bluetooth
WLAN specifications: IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac
WLAN encryption: WPA2
Design
Housing color: black
Speaker cover color: black
Enclosure materials: MDF, Aluminum
Surface: matte
Front color: black
Color: black
Construction
Housing property: Bass reflex
Construction: Coaxial system
Number of tweeters: 1
High-frequency chassis: 25 mm
Material High Tones: Fabric
Number of midrange drivers: 1
Midrange driver: 130 mm
Materials midrange driver: Aluminum, Paper
Number of woofers: 1
Woofer: 160 mm
Woofer Material: Kevlar
Number of bass reflex ports: 1
Position of bass reflex port: Back side
Dimensions and scope of delivery
Weight: 10,3 kg
Scope of delivery: Speaker cable, operating manual, power cable
Width: 210 mm
Height: 430 mm
Depth: 270 mm
Further properties
Compatibilities: Devices with 3.5mm output, notebook, other devices with Bluetooth, tablet, MP3 player, smartphone
Areas of application: HiFi system, living room, multiroom, mobile phone
Configurations: Stand, vertical, shelf
Market launch: 2018
