Indoor unit
| Cooling airflow (indoor unit) |
744 m³/h |
| Heating airflow (indoor unit) |
744 m³/h |
| Indoor unit type |
Wall-mountable |
| Indoor units quantity |
1 |
| Indoor unit depth |
242 mm |
| Indoor unit height |
295 mm |
| Indoor unit width |
790 mm |
| Noise level (indoor unit) |
62 dB |
| Indoor unit weight |
12000 g |
Technical details
| Cooling capacity in watts (min) |
300 W |
| Cooling capacity in watts (max) |
5000 W |
| Heating capacity in watts (min) |
300 W |
| Heating capacity in watts (max) |
6500 W |
| Type |
Air conditioner indoor unit |
| Built-in display |
N |
| Hose length (max) |
20 m |
| Heating capacity in watts (nominal) (Average heating season) |
5500 W |
| Cooling capacity in watts (nominal) |
4500 W |
| Ionizer |
Y |
Power
| Power consumption (cooling) (min) |
70 W |
| Power consumption (cooling) (max) |
1490 W |
| Power consumption (heating) (min) |
70 W |
| Power consumption (heating) (max) |
1700 W |
| Energy efficiency class (heating) (Average heating season) |
A |
| Annual energy consumption (cooling) |
610 kWh |
| Energy efficiency class (cooling) |
A |
Additionally
| Cooling energy efficiency |
3.69 |
| Heating energy efficiency |
4.1 |
| Remote controlled |
Y |
4500/5500 W, A/A, 3.69 EER, 4.1 COP, 372 - 744 m3/h, 103 - 207 l/s, 30 - 62 dB, 12000 g, White
The power of Daisaeikai Ionizer
By generating more than 1 million negative ions for every square centimeter of air, the Daiseikai ionizer will invite the freshness of nature into your personal place. The invigorating atmosphere of forest and waterfalls can be experience directly in your own home.
SuperDaiseikai has been designed and created with the objec tive to provide excellence, respecting the latest eco-evolution trends and maintaining the ultimate comfort.
Improved class A efficiency with COP value above 5 (5,36 for size 10). New technology and advanced electronic reduced the Annual E nergy Consumption of 30%.
Dual stage compressor improve the load effi ciency in a wide ran ge of conditions. Fast filtration: impurities are ionized by the ion charger an d absorbed by the new heat exchanger.
Self cleaning to prevent the growth of mold inside the unit. Nordic version with heat on the base plate of outdoor unit and winter operation mode.
