Performance
| Receiver sensitivity |
2.4GHz:\n11g 54M: -76dBm@10% PER\n11n HT20 MCS7: -73.5dBm@10% PER\n11n HT40 MCS7: -71dBm@10% PER\n5GHz:\n11a 6Mbps:-93dBm@10% PER\n11a 54Mbps: -75dBm@10% PER\n11ac HT20 MCS8: -67dBm@10% PER\n11ac HT40 MCS9: -62.5dBm@10% PER\n11ac HT80 MCS9: -59.5dBm@10% PER |
| Ethernet LAN data rates |
10, 100, 1000 Mbit/s |
| Operating modes |
AP, Repeater/Bridge w / AP, Client, Multi-SSID |
| Wi-Fi data rate (max) |
750 Mbit/s |
| 2.4 GHz |
Y |
| 5 GHz |
Y |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u |
| Reset button |
Y |
| Certification |
CE, FCC, RoHS |
Packaging content
| Cables included |
LAN (RJ-45) |
| Quick start guide |
Y |
Design
| Placement |
Table |
| Internal |
N |
| LED indicators |
Y |
Security
| Security algorithms |
64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK, WPS |
Power
| Output voltage |
12 V |
| Power over Ethernet (PoE) |
Y |
| Output current |
1 A |
Antenna
| Antenna type |
External |
| Antennas quantity |
2 |
| Detachable antenna(s) |
Y |
Weight & dimensions
| Depth |
162 mm |
| Width |
242 mm |
| Height |
44 mm |
Operational conditions
| Storage temperature (T-T) |
-40 - 70 °C |
| Storage relative humidity (H-H) |
10 - 90% |
| Operating altitude |
5 - 90 m |
System requirements
| Compatible operating systems |
Microsoft Windows 98SE, NT, 2000, XP, Vista, Windows 7, 8, 8.1, 10, Mac OS, NetWare, UNIX, Linux |
Additionally
| Colour of product |
Black |
| Transfer rate (Mbps) |
1000 Mbit/s |
| On/Off switch |
Y |
| AC adapter bundled |
Y |
| Ethernet LAN (RJ-45) ports quantity |
1 |
| Operating temperature range (T-T) |
0 - 40 °C |
AC750 Wireless Gigabit Access Point, Dual Band, Passive PoE
Lightning-Fast AC750 Dual Band Wi-Fi
Upgrade your home or office network with the latest-generation of dual band 802.11ac access point, which offers combined speeds of up to 750Mbps and is perfectly suited to serve multiple devices at the same time. The 5GHz band is ideal for Ultra-HD streaming video and online gaming, while the 2.4GHz band is there for all of your everyday Internet needs, like sending email and browsing the Internet.
Superior Wi-Fi Coverage
Two external detachable antennas help strengthening and expanding your Wi-Fi signal,
providing superior coverage to eliminate dead zones.
Passive PoE Supported
More Flexible Deployment
The AP200 is able to be powered using an Ethernet cable up to 30 meters. Allow you to place the device more flexible and effortless.
Gigabit-Class Wired Performance
The Ethernet port can provide gigabit-class Internet access or an ultra-fast connection for wired device such as smart TV, game console, etc.
Easy Setup and Use
The AP200’s powerful web interface allows it to be set up and configured in a matter of minutes. The intuitive design makes installation faster and easier than ever and allows users to monitor and personalize settings for a wide range of functions.
