Security
| Authentication method |
Captive Portal, MAC Address |
| Security algorithms |
SSID, WPA, WPA-PSK, WPA2-PSK |
| Number of SSID support |
16 |
| MAC address filtering |
Y |
Performance
| VLAN support |
Y |
| Ethernet LAN data rates |
10, 100 Mbit/s |
| Wireless isolation |
Y |
| Wi-Fi data rate (max) |
1750 Mbit/s |
| 2.4 GHz |
Y |
| 5 GHz |
Y |
| Auto Wireless Distribution System (WDS) |
Y |
| Wi-Fi Multimedia (WMM)/(WME) |
Y |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Reset button |
Y |
| Certification |
CE, FCC, RoHS |
Power
| Input voltage |
12 V |
| Power consumption (typical) |
12.7 W |
| Power over Ethernet (PoE) |
Y |
| Input current |
1.5 A |
Design
| Placement |
Ceiling |
| Internal |
N |
| Cable lock slot |
Kensington |
Weight & dimensions
| Depth |
180 mm |
| Width |
180 mm |
| Height |
47.5 mm |
Operational conditions
| Storage temperature (T-T) |
-40 - 70 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage relative humidity (H-H) |
5 - 90% |
Additionally
| Colour of product |
White |
| Transfer rate (Mbps) |
1750 Mbit/s |
| AC adapter bundled |
Y |
| Ethernet LAN (RJ-45) ports quantity |
1 |
| Operating temperature range (T-T) |
0 - 40 °C |
1750 Mbps, IEEE802.3at PoE, 12VDC/1.5A, 12.7W, 2.4GHz + 5GHz, IEEE 802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b, IEEE 802.11a
- Simultaneous 450Mbps on 2.4GHz and 1300Mbps on 5GHz totals 1750Mbps Wi-Fi speeds
- Hardware wireless controller enables administrators to easily manage hundreds of CAPs
- Support Power over Ethernet (802.at) for convenient and affordable installation
- Simple mounting design for easy attachment to a wall or ceiling
- Captive portal provides on convenient method of authentication for Wi-Fi guests
- Enterprise class Wi-Fi security helps to decrease network security threats
- Multi-SSID divides multiple wireless networks for different user types
- Band Steering automatically moves dual band devices onto the wider 5GHz band for faster connections
- Load balance ensures large numbers of users have smooth network experiences in high density business networks
- FAT/FIT mode switchable provides a range of network possibilities
