Camera types: IP camera, infrared camera, cylinder camera
Series: tp-link VIGI
Equipment
Functions: Password protection, IR-Cut Filter, Cloud function, IP address filter, with IR-LEDs, day and night function, Region of Interest (ROI), with notification function, suitable for network recorder, Low-Speed-Shutter
Video functions: with night vision function, with vehicle detection, with live viewing, with person detection, with video stream
Connections: 5.5 mm coaxial, RJ-45 PoE
Power supply: PoE (Power over Ethernet), DC 12 V
Housing
Housing color: white
Mounting types: Wall mounting, ceiling mounting, surface mounting
Protection class: IP67
Application area: outside
Swivel range: +/- 90°
Tilt range: +/- 90°
Outdoor functions: dust-protected, waterproof
Temperature range: -30 to 60 °C
Weight: 200 g
Dimensions (W x H x D): 174 x 74 x 71 mm
Network
Interface: RJ45
System requirements software: Firefox, Safari, Chrome, Edge
Protocols: TCP/IP, UDP, ICMP, DHCP, HTTP, HTTPS, SSL/TLS, NTP, DNS, RTSP, ONVIF, UPnP UDP
Lens
Objective focal length: 4 mm
Lens properties: fixed focal length
Lens mount: M12
Light sensitivity IR: 0 Lux
Light sensitivity without IR: 0,01 Lux
Video & Image
IR range: 30 m
Number of infrared LEDs: 2
Resolution: 2.304 x 1.296 Pixel
Images per sec.: 5, 30, 10, 15, 20, 25, 1
horizontal field of view: 82,5 °
vertical field of view: 44,9 °
diagonal viewing angle: 99,3 °
Sensor type: 1/2,8" Progressive Scan CMOS
Image sensor: 3 Megapixel
Image enhancements: Digital Wide Dynamic Range (D-WDR), Digital Noise Reduction (3D-DNR), Backlight Compensation (BLC), Highlight Compensation (HLC)
Video formats: H.264, H.265, H.264+, H.265+
Further properties
suitable for: Darkness
