Camera types: IP camera, PTZ camera, infrared camera
Series: tp-link VIGI
Equipment
Equipment: with integrated speaker, with microphone, with integrated lamp
Functions: Motion detection, alarm function, with notification function, electronic panning, tilting, zooming (ePTZ), IP address filter, cloud function, password protection, pan/tilt function, Region of Interest (ROI)
Audio function: 2-way audio
Video functions: with night vision function, with live viewing, with person detection, with vehicle detection, with video stream
supported memory cards: microSD
Connections: RJ-45 PoE, 5.5 mm Coaxial
Power supply: DC 12 V, PoE (Power over Ethernet)
Housing
Housing colors: white, black
Mounting types: Ceiling mount, wall mount, surface mount
Protection class: IP66
Application area: outside
Swivel range: 348 °
Tilt range: 105 °
Temperature range: -30 to 60 °C
Dimensions (W x H x D): 120 x 172 x 203 mm
Network
Interface: RJ45
Wi-Fi standard: 802.3at PoE
App Support: yes
LAN standard: Ethernet 10/100
System requirements software: Chrome, Edge, Firefox, Safari
Protocols: TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, ONVIF
Lens
Objective focal length: 4 mm
Lens properties: fixed focal length
Lens mount: M16
Light sensitivity without IR: 0 Lux
Video & Image
Resolution: 2.688 x 1.520 Pixel
Images per sec.: 30
horizontal field of view: 104 °
vertical field of view: 55 °
diagonal viewing angle: 127 °
Sensor type: 1/1,79” Progressive Scan CMOS
Image sensor: 4 Megapixel
Image enhancements: Backlight compensation (BLC), digital noise reduction (3D-DNR), highlight compensation (HLC), Digital Wide Dynamic Range (D-WDR)
Video formats: H.265+, H.265, H.264+, H.264
Video recording: Color
Audio formats: G.711
Further properties
Operating voltage: 12 V
suitable for: Darkness
