Ports & interfaces
| Audio RCA inputs |
1 |
| Audio RCA outputs |
1 |
| Power over Ethernet (PoE) |
Y |
| USB 3.0 (3.1 Gen 1) Type-A ports quantity |
1 |
| VGA (D-Sub) output ports |
1 |
Performance
| Ethernet LAN data rates |
1000 Mbit/s |
| Supported network protocols |
IPv4, IPv6, UDP, TCP, ICMP, SSL, TLS, ONVIF v2.2, DHCP, NTP, DNS, DDNS, SMTP, FTP, SNMP, HTTP, UPnP, RTSP, RTP, RTCP |
| Video input channels |
16 channels |
Features
| LED indicators |
Y |
| Rack mounting |
Y |
Storage
| Hard drive capacity |
4000 GB |
| Number of hard drives installed |
1 |
| Number of hard drives supported |
2 |
| Maximum storage capacity |
6 TB |
| Hard drive interface |
Serial ATA II |
Packaging content
| Handheld remote control |
Y |
| CD manual |
Y |
| Quick installation guide |
Y |
Power
| Power consumption (max) |
10 W |
Additionally
| Выход HDMI |
Y |
| On/Off switch |
Y |
| AC adapter bundled |
Y |
| Ethernet LAN (RJ-45) ports quantity |
1 |
HDMI, VGA, 1920 x 1080 p/60 Hz, 2 x RCA, 16 channel, SATA, IEEE 802.3/802.3u/802.3x/802.3ab, RJ-45, 4 TB HDD, USB 2.0/USB 3.0, 100 - 240 V, 50 - 60 Hz, 1.7 A, 12 V DC, 10 W, 380 x 270 x 45 mm, 2.7 kg
- 16-channel network video recorder
- Manage up to 16 TRENDnet cameras*
- Concurrent 1080p HD video recording for all channels
- Preinstalled 4 TB HDD provides one week of continuous 1080p video recording***
- Two 3.5” SATA II bays support up to a 12 TB of storage (6 TB per bay, HDDs sold separately)
- Advanced video playback
- Rack mountable
- ONVIF compliant
TRENDnet’s 16-channel HD NVR, model TV-NVR2216D4, offers a comprehensive rack mountable camera anagement solution. This NVR includes a preinstalled 4 TB hard drive and connects up to eight cameras*. Install up to 12 terabytes of storage (additional hard drives sold separately) to record three weeks of continuous video from eight HD cameras**. The TV-NVR2216D4 features advanced video playback and free iOS® / Android™ apps available.
1080p HD NVR
This 1080p HD NVR includes a preinstalled 4 TB hard drive and supports a total storage capacity of up to 12 TB and manages up to eight network cameras - cameras and display sold separately.
Easy Installation
The NVR auto-recognizes and powers TRENDnet PoE cameras* – simply connect compatible TRENDnet PoE cameras and start recording surveillance video.
*See list of compatible cameras www.trendnet.com/products/nvr-solutions
** Three weeks of continuous recording 16 cameras in 1080p resolution at 30 fps (medium VBR) with 12 TB of storage (HDDs not included)
*** One week of continuous recording per camera with preinstalled 2 TB HDD and 8 x 1080p cameras at 30 fps (medium VBR)
Intuitive Interface
Users will find the management interface intuitive and easy to use – quickly navigate live view preferences, recording schedules, and advanced playback options.
