Power
| Input voltage |
24 V |
| Input current |
0.5 A |
| Power over Ethernet (PoE) |
Y |
Performance
| Ethernet LAN data rates |
10, 100 Mbit/s |
| Internal memory |
32 MB |
| Flash memory |
8 MB |
| 2.4 GHz |
Y |
| Maximum outdoor range |
10000 m |
| Frequency band |
2.412-2.462 GHz |
Antenna
| Antenna gain level (max) |
8 dBi |
Additionally
| Ethernet LAN (RJ-45) ports quantity |
1 |
| Transfer rate (Mbps) |
150 Mbit/s |
2.4 GHz, 10/100 Ethernet RJ-45, 32 MB SDRAM, 8 MB Flash, 5+ km, PoE
<b>Compact CPE Design</b>
The NanoStationM features the CPE design that expanded the global Wireless ISP industry.
<b>Plug and Play Installation</b>
The NanoStation M requires no tools for assembly; only a single wrench is required for pole-mounting.
<b>Versatile Application Use</b>
The NanoStation M can be deployed for Point-to-Point (PtP) bridging, wireless connectivity to a video surveillance system, or use as an airMAX CPE.
<b>Dual Ethernet Connectivity</b>
With software-enabled PoE output, the secondary Ethernet port can power an external device, such as a PoE security camera, for seamless IP video integration.
<b>Advanced Software Technology</b>
Ubiquiti’s airMAX technology is proven in millions of deployments worldwide, exhibiting outstanding performance in outdoor environments. The TDMA airMAX protocol enables unprecedented scalability, high throughput and low latency in unlicensed, multipoint networks.
<b>Window/Wall Mounting Kit</b>
Use the NanoStation Mount to quickly mount the NanoStationM on a window or wall. 180° vertical or horizontal adjustment allows for custom positioning.
