Vertiv 02.110.084.1 Freestanding 24U Grey rack

48.26 cm (19 ") , 24U, 600 x 1145 x 800 mm, 39 kg, Light Grey - For components compliant with IEC 297-3.
- Access from all sides with removable covers.
- Flexible assembly of the components using mounting holes.
- Cable entry via rear panel (optional via top cover/bottom cover).
- Heat loss discharge via own convection or with fan unit on the rear panel (accessory).
- Door opening angle, 180°.
- Front door with safety glass, lockable.

<b>Jumpering space</b>
- Front 110 mm.

<b>Load rating</b>
- 2000 N static.

<b>Protection rating</b>
- IP 20.

<b>Material / Finish</b>
- Basic rack, extruded aluminum, polished.
- Corner connector, die-cast, polished.
- Covers, sheet steel, powder-coated texture.
- Glass infill front door, single safety glass panel.

<b>Color</b>
- RAL 7035, light-grey.

<b>Scope of delivery</b>
- 1 x basic rack.
- 2 x side panels, closed; hinged on both sides.
- 1 x top cover, closed.
- 1 x glass front door, lockable.
- 1 x rear door with cable entry, lockable, prepared for ventilation unit.
- 4 x 19" sheet steel vertical extrusions.
- 1 x grounding set.
- 4 x leveling feet.

<b>How supplied</b>
- Assembled.
