Display
| Sync-on-green (SOG) |
Y |
| Separate H/V sync |
Y |
| Display diagonal |
22 " |
| Vertical scan range |
50 - 76 Hz |
| Touchscreen technology |
Capacitive |
| Contrast ratio (dynamic) |
50000000:1 |
| Response time |
7 ms |
| Composite sync |
Y |
| Contrast ratio (typical) |
1000:1 |
| Display resolution |
1920 x 1080 pixels |
| Viewing angle, horizontal |
178 ° |
| Viewing angle, vertical |
178 ° |
| Display brightness |
250 cd/m² |
| Full HD |
Y |
| Display |
IPS |
| Display type |
TFT |
Power
| Power consumption (PowerSave) |
19 W |
| Power consumption (typical) |
25 W |
| Power consumption (max) |
28 W |
| AC input voltage |
100-240 V |
| AC input frequency |
50/60 Hz |
| Power supply type |
AC |
Ports & interfaces
| Cables included |
AC, Audio (3.5mm), HDMI, USB |
| Headphone outputs |
1 |
| DisplayPorts quantity |
1 |
| USB 3.0 (3.1 Gen 1) Type-A ports quantity |
2 |
| HDMI ports quantity |
1 |
| VGA (D-Sub) ports quantity |
1 |
Weight & dimensions
| Dimensions (W x D x H) with stand |
490.3 x 298.8 x 129.7 mm |
| Weight with stand |
3600 g |
| Depth |
47.3 mm |
| Weight |
3600 g |
| Width |
490.3 mm |
| Height |
298.8 mm |
Performance
| Number of speakers |
2 |
| Number of simultaneous touchpoints (Windows 7) |
10 |
| Connection to PC |
Y |
| RMS rated power |
6 W |
| Touch technology |
Multi-touch |
| Built-in speaker(s) |
Y |
Ergonomics
| VESA mounting |
Y |
| VESA mounting interfaces |
100 x 100 mm |
| Tilt adjustment |
Y |
| Wall mountable |
Y |
| Tilt angle |
20 - 70 ° |
Operational conditions
| Operating relative humidity (H-H) |
20 - 90% |
Technical details
| Mac compatibility |
Y |
| Glass protection |
Y |
Packaging data
| Package depth |
371 mm |
| Package weight |
4700 g |
| Package width |
550 mm |
| Package height |
114 mm |
Additionally
| Display scan frequency (horizontal) |
24 - 82 kHz |
| Display diagonal |
55.88 cm |
| Operating temperature range (T-T) |
0 - 40 °C |
22”, 1920 x 1080, 1000:1, 7ms, TFT, 178 º / 178 º , 21,5”, 50000000:1, LED, 250 cd/m2, 7H, USB 3.0, HDMI, VGA, DisplayPort, 3W x2, 19W, 22W, 25W, 28W, 100-240 V, 50/60Hz, OSD, 0 º - 40 º C, 20%-90%, VESA, 24-82 kHz, 50-76 kHz, 20 º -70 º, 4.7 kg, 3.6 kg, 3.6 kg
10-Point Projected Capacitive Touch
Touch screens with projected capacitive touch can recognize up to 10 points of simultaneous contact, allowing for a highly accurate and ultra-responsive touch experience. With smooth and responsive touch capabilities, this touch display is ideal for home entertainment, office work, education, and commercial use.
SuperClear IPS Panel Technology
Enjoy accurate and vivid colors with consistent levels of brightness no matter the vantage point. With SuperClear IPS panel technology, this monitor delivers the same image quality whether you are looking at the screen from above, below, the front, or the side.
Frameless Design
Say goodbye to the thick, clunky plastic frames set over the edges of traditional monitors. This monitor features a frameless edge-to-edge glass faceplate with an ultra-slim bezel beneath the glass. With its sleek, eye-catching design, this elegant monitor looks as good as it performs.
Versatile Connectivity
DisplayPort, HDMI, and VGA inputs give you the freedom to connect your monitor to a variety of devices.
Durable, Scratch-resistant Screen
This touch display is designed with a durable, protective glass faceplate. This provides increased scratch protection to ensure durability, as well as a consistent, high-quality touch experience in high-traffic areas such as educational settings, or other public environments where the touch display can be used as a kiosk.
Stable Bookstand Design
A stable, integrated bookstand design makes it easy to adjust the angle of this display for a better user experience. The display can tilted or laid completely flat on a tabletop for a more comfortable work environment.
Enhanced ViewingComfort
Flicker-Free technology and a Blue Light Filter help to eliminate eye strain from extended viewing periods.
Cross-platform Compatibility
Cross compatibility with a wide range of operating systems include Windows 10, and certain Android and Linux versions.
VESA-CompatibleMount
Mount the monitor as you see fit using its convenient VESA-compatible mount design.
3-year LimitedWarranty
Have peace of mind in the quality and reliability of your ViewSonic monitor—backed by one of the industry’s best pixel performance policies and a 3-year limited warranty.
