Camera types: IP camera, Dome camera, Infrared camera
Series: Vivotek FD
Equipment
Equipment: with microphone
Functions: with notification function, vandal-resistant, NAS-capable, timestamp, IR-cut filter, privacy zones, ONVIF
Video function: with night vision function
Number of cameras: 1
Notification type: HTTP, FTP Server, NAS Server
Storage recording device: 2 GB
supported memory cards: micro SDHC, microSD, microSDXC
Connections: RJ-45 PoE, RJ-45, Digital I/O, Line In (Cinch), Line Out (Cinch), Mic In
Sensor: Motion Sensor
Ppower supply: PoE (Power over Ethernet)
Housing
Housing color: white
Mounting types: Surface mounting, Ceiling mounting, Wall mounting
IP rating: IP20
Areas of application: inside, outside
Outdoor functions: splash-proof, dust-tight, dust-protected, waterproof, weatherproof
Temperature range: -20 to 50 °C
Weight: 920 g
Dimensions (W x H x D): 155 x 103 mm
Network
Interfaces: 802.3af (PoE), RJ45
LAN Standards: Ethernet 10/100 Base-T (802.3), Ethernet 10/100 Base-TX (802.3u)
System Requirements Software: Firefox 7 to 10, Firefox 9 or higher, Internet Explorer 7.0 or higher
System requirements Operating system: Microsoft Windows 7, Microsoft Windows 8, Microsoft Windows 2000, Microsoft Windows Vista, Microsoft Windows XP
Lens
Objective focal length: 2,8 mm
Lens properties: fixed focal length
Light sensitivity IR: 0.01 lux
Light sensitivity without IR: 0.15 Lux
Aperture: 1,8
Video & Image
Infrared range: 30 m
Number of infrared LEDs: 8
Resolution: 1,920 x 1,080 pixels
Images per second.: 30
horizontal field of view: 122 °
vertical field of view: 66 °
Sensor Type: 1/2.7" Progressive Scan CMOS
Image sensor: 2 Megapixel
Image enhancements: automatic light control (ALC), automatic gain control (AGC), automatic white balance (AWB), digital noise reduction (3D-DNR), Wide Dynamic Range (WDR), backlight compensation (BLC)
Digital zoom: 48 times
Video Formats: H.264, MJPEG
Video recordings: Color, Black & White, HD
Audio Formats: G.711, G.726
Image file format: JPEG
Photo resolution: 2 Megapixel
Additional features
Scope of delivery: User manual, Mounting hardware, Software CD
Operating voltage: 12 V
suitable for: Darkness
