Camera type: IP camera
Series: IP camera
Equipment
Equipment: with microphone
Functions: with notification function, NAS-capable, timestamp, IR-cut filter, private zones, ONVIF
Video function: with night vision function
Number of cameras: 1
Notification type: SMTP, HTTP, FTP Server, NAS Server
supported memory cards: micro SDHC, microSD, microSDXC
Connections: Mic In, RJ-45, RJ-45 PoE, Line In (Cinch), Line Out (Cinch), Digital I/O
Sensor: Motion Sensor
Ppower supply: PoE (Power over Ethernet)
Housing
Housing color: white
Mounting: Wall mounting
IP rating: IP20
Application area: inside
Swivel range: 46 - 90 °
Tilt range: 35 - 68 °
Temperature range: -10 to 50 °C
Weight: 766 g
Dimensions (W x H x D): 210 x 70 x 63 mm
Network
Interfaces: 802.3af (PoE), RJ45
LAN Standards: Ethernet 10/100 Base-T (802.3), Ethernet 10/100 Base-TX (802.3u)
System Requirements Software: Firefox 7 to 10, Firefox 9 or higher, Internet Explorer 7.0 or higher, QuickTime, VLC
Protocols: IPv4/v6, TCP/IP, HTTP / HTTPS, UPnP, RTP/RTSP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP, 802.1X, UDP, IC
System requirements Operating system: Microsoft Windows 2000, Microsoft Windows 7, Microsoft Windows 8, Microsoft Windows Vista, Microsoft Windows XP
Lens
Lens: Zoom lens
Objective focal length: 4 - 9 mm
Lens properties: Variable focal length
Light sensitivity IR: 0.001 lux
Light sensitivity without IR: 0.07 Lux
Aperture: 2,4
Video & Image
Resolution: 2,560 x 1,920 Pixels
Images per second.: 60
Sensor Type: 1/1.8" Progressive Scan CMOS
Image sensor: 5 Megapixel
Image enhancements: automatic light control (ALC), automatic gain control (AGC), automatic white balance (AWB), digital noise reduction (3D-DNR), backlight compensation (BLC), Wide Dynamic Range (WDR)
Digital zoom: 48 times
Video Formats: H.264, H.265, MJPEG
Video recordings: Color, Black & White, HD
Audio Formats: G.711, G.726
Image file format: JPEG
Additional features
Scope of delivery: User manual, Mounting hardware, Cable gland, Quick installation guide, Software CD
Operating voltage: 24 V
