Camera types: IP Camera, Infrared Camera
Equipment
Equipment: with microphone
Functions: with notification function, vandal-proof, NAS-capable, IR-Cut Filter, privacy zones, ONVIF
Video function: with night vision function
Number of cameras: 1
Notification type: HTTP, SMTP, NAS Server, FTP Server
supported memory cards: SD, micro SDHC, SDXC
Connections: RJ-45 PoE, RJ-45, Line In (Cinch), Line Out (Cinch), Digital I/O, Mic In
Sensor: Motion Sensor
Ppower supply: PoE (Power over Ethernet)
Housing
Housing color: white
Mounting types: Surface mounting, Wall mounting
IP rating: IP20
Areas of application: inside, outside
Swivel range: 1.6 - 32.6 °
Tilt range: 2.9 - 55.4 °
Outdoor functions: splash-proof, dust-tight, dust-protected, waterproof, weatherproof
Temperature range: -50 to 50 °C
Weight: 4.300 g
Dimensions (W x H x D): 147 x 375 x 322 mm
Network
Interfaces: 802.3af (PoE), RJ45
LAN Standards: Ethernet 10/100 Base-T (802.3), Ethernet 10/100 Base-TX (802.3u)
System Requirements Software: Firefox 7 to 10, Firefox 9 or higher, Internet Explorer 7.0 or higher, QuickTime, VLC
Protocols: IPv4/IPv6, TCP/IP, HTTP/HTTPS, UPnP, RTP/RTSP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP, 802.1X, UDP, ICMP, A
System requirements Operating system: Microsoft Windows 2000, Microsoft Windows 8, Microsoft Windows 7, Microsoft Windows Vista, Microsoft Windows XP
Lens
Lens: Zoom lens
Objective focal length: 4,7 - 94 mm
Lens properties: Variable focal length
Light sensitivity IR: 0.01 lux
Light sensitivity without IR: 0.26 Lux
Aperture: 3,5
Video & Image
Infrared range: 150 m
Resolution: 1,920 x 1,080 pixels
Images per second.: 60
Sensor Type: 1/3" Progressive Scan CMOS
Image sensor: 2 Megapixel
Image enhancements: automatic light control (ALC), automatic gain control (AGC), automatic white balance (AWB), Wide Dynamic Range (WDR), backlight compensation (BLC)
Digital zoom: 20x
Video Formats: H.264, H.265, MJPEG
Video recordings: Color, HD
Audio Formats: G.711, G.726
Image file format: JPEG
Additional features
Scope of delivery: User manual, Mounting hardware, Quick installation guide, Software CD
Operating voltage: 24 V
suitable for: Darkness
