Ports & interfaces
| HDMI in |
1 |
| Remote (IR) input |
2 |
| Remote (IR) output |
2 |
| RJ-45 input ports |
1 |
| RJ-45 output ports |
1 |
| DC-in jack |
Y |
Technical details
| Type |
AV transmitter & receiver |
| Cable types supported |
Cat5e, Cat5, Cat6 |
| Maximum transfer distance |
50 m |
| HDCP |
Y |
| Bandwidth |
6.75 Gbit/s |
| Audio system |
Multichannel |
Packaging content
| Mounting brackets included |
Y |
| IR receiver included |
Y |
| IR blaster included |
Y |
Power
| Power consumption (transmitter) (max) |
2.5 W |
| Power consumption (receiver) (max) |
5 W |
WyreStorm HDBaseT Extender Set with 2-Way IR (50m/164ft)
Designed with the needs of the installer in mind.
The EX-1UTP-IR-50 Extender set comprises of a Transmitter and Receiver to distribute full, uncompressed HD 1080p video @60Hz, HD multichannel audio with bidirectional discrete IR control of source and display from either location over distances of up to 50m/164ft using a single shielded or unshielded Cat5e/6 cable..
Transmitters include EDID management to manually handle device communication via DIP switch setting, with Receivers containing long cable mode to further encourage successful transmission. Both units also feature protection against ESD (electrostatic discharge) to further stabilise transmission with LED indication on the unit housing providing clear confirmation of power and signal link status. Both units also contain DIP settings .
Additionally, the EX-1UTP-IR-50 is fully cascadable, with transmission lengthened by connecting to multiple 50m/164ft extender sets for increased distribution and even greater flexibility, whatever the installation environment.
- HDBaseT extenders capable of 1080p HD @60Hz and HD multichannel audio transmissions up to 50m (164ft) under perfect conditions*
- Transmits discrete wide-band two-way IR control signal together within the HDMI signal over a single Cat5e/6 cable
- Fully supports 3D applications - frame packing/sequential (Blu-ray) and Interlaced stereoscopic (satellite/cable broadcasts)
- Supports 36bit Deep Colour
- HDMI V1.4
- Cable termination follows IEEE-568B standards
- HDCP compliant
- Automatically adjusts feedback, equalization and amplification of signal for easy installation.
- EDID management on Transmitter and DIP Setting on Receiver to aid communication between devices and transmission.
- LED indication for visual power and HDMI / HDBaseT video signal status.
- Fully cascadable to further lengthen transmission and increase your distribution capabilities.
